ID
1332438
$ 1,514.47
1-2 weeks delivery time
-
+
The Johnson Pump 10-13656-02 CM10 circulation pump delivers dependable coolant flow for water and water/glycol mixtures, supporting up to 60% glycol and fresh water operation. A protected 12/24V DC motor with IP67 sealing, permanent-magnet design, and ball bearings is built for continuous duty, while the PPA plastic housing and impeller with a stainless-steel shaft help ensure durable performance. It handles fluid temperatures from -40 °C to +100 °C, supports up to 2.5 bar system pressure, and offers Ø16 mm or Ø20 mm hose connections with universal bracket mounting for flexible installation.
- Description
- Ask a Question
-
Johnson Pump 10-13656-02 CM10 Coolant Circulation Unit
This Johnson Pump circulation pump is designed to move coolant through systems using water or water/glycol mixtures. With a robust motor protection rating and materials selected for long service life, it supports continuous operation while helping maintain stable fluid circulation.
Application
- Circulation of water/glycol mixture (maximum 60% glycol)
- Circulation of pure fresh water
Technical Specifications
Brand Johnson Pump Part Number 10-13656-02 Series Johnson CM10 Model Reference C096 Rated Voltage (As Listed) 27.2 V Motor Supply 12/24 V DC Ingress Protection IP67 Motor Type Permanent Magnet, Ball-Bearing Motor Duty Designed for Continuous Operation Pump Housing Material PPA Plastic Impeller Material PPA Plastic Shaft Material Stainless Steel Compatible Fluids Water/Glycol Mixture (Max. 60% Glycol), Pure Fresh Water Fluid Temperature Range Min -40 °C, Max +100 °C Maximum System Pressure 2.5 bar Hose Connection Ø 16 mm or Ø 20 mm (3/4 in) Dry Running Capability Maximum 30 minutes Power Consumption Maximum 14 W (CM10); 27 W (CM30) Mounting Universal Bracket, Flat Mounting Dimensions (L × W × H) 177 mm × 68 mm × 85 mm (6.97 in × 2.68 in × 3.35 in) Weight 0.53 kg (1.2 lb) Diameter DIA25 (Plastic)
Product Details
- Type: Circulation pump
- Construction: Plastic pump housing and impeller with a stainless-steel shaft
- Protection: IP67-rated motor protection for demanding environments
Features
- Built for continuous-duty circulation
- Supports water/glycol mixtures up to 60% glycol and pure fresh water
- Wide operating temperature range from -40 °C to +100 °C
- Universal bracket and flat mounting option for flexible installation
-
