The VDO 333-065-001G Cockpit International tachometer is a compact 24 V analog RPM instrument with a 0–3,000 RPM range, built for dependable engine-speed monitoring in vehicle dashboards and cockpits. Designed for VDO engine monitoring installations, it accepts a tach signal from the alternator W terminal or ignition terminal 1, and mounts cleanly in a 100 mm panel cutout with secure spinlock-nut or bracket locking options. Simple electrical integration is supported by an 8-pole AMP male blade connector for the instrument and a separate 4-way AMP male blade connector for illumination.
- Description
- Ask a Question
-
VDO Cockpit International 24 V Tachometer Gauge 0–3,000 RPM
Built for clear engine-speed readout, the VDO 333-065-001G is an analog Cockpit International tachometer engineered for VDO engine monitoring dashboards and cockpits. With a 0–3,000 RPM scale, compact 100 mm installation size, and robust electrical connections, it is a practical choice for 24 V applications that require stable, easy-to-read RPM information.
Compatibility
- 24 V DC vehicle electrical systems (21.5–30 V DC operating range)
- Installations using alternator terminal W as the tachometer signal source
- Installations using ignition terminal 1 as the tachometer signal source
- VDO Cockpit International engine monitoring dashboards and cockpits
Product Details
- Brand: VDO
- Part Number: 333-065-001G
- Category: Tachometers
- Series: VDO Cockpit International
- Application: VDO engine monitoring
- Measurement Type: Analog RPM
- Predecessor: 333-065-001C
Technical Specifications
Measurement Range 0–3,000 RPM Operating Voltage 21.5–30 V DC (24 V system) Current Consumption (Without Illumination) < 100 mA Panel Cutout Diameter 100 mm (4 in) Outside Diameter 105 mm (4 1/8 in) Installation Depth 91 mm Locking Height With Spinlock Nut Optional 0.5–23 mm Locking Height With Bracket 0.5–12 mm Flush Mount No Instrument Connection 8-pole AMP male blade connector (6.3 × 0.8 mm) Illumination Connection 4-way AMP male blade connector (6.3 × 0.8 mm) Signal Input Alternator terminal W; ignition terminal 1 Reverse Polarity Protection Yes Deflection Angle 320° Dial Color Black Pointer Red backlight Programming Yes Lens Single anti-glare plastic Bezel Triangular black (threaded ring); interchangeable with special tool Front Protection Class IP64 (DIN 40050); ozone proof; UV proof Rear Protection Class IP42 (DIN 40050) Operating Temperature -20°C to +70°C EMC According to EN 13309 and ISO 13766 Nominal Position NL 0 to NL 90 (DIN 16257) Housing Plastic, flame retardant Color Black Weight 0.42 kg EAN Code 410359070036 HS Code 90292031 Country of Origin Switzerland
Features
- Clear 0–3,000 RPM analog display for confident engine-speed control
- Designed for 24 V systems and stable operation across a wide DC supply range
- Flexible signal pickup from alternator W or ignition terminal 1 for straightforward integration
- Secure mounting options using a spinlock nut or bracket to suit different panel thicknesses
- Durable environmental protection with IP64 front rating for demanding cockpit and dashboard use
-
