ID
1224518
$ 74.18
1-2 weeks delivery time
-
+
The BEP 185040F-01-1 is a heavy-duty single pole thermal circuit breaker from the BEP 184 & 185 Series, designed for surface mounting and featuring a switchable reset mechanism with visible trip indication for manual circuit isolation. It is rated 40A, 30V DC, with a 3000A interrupt capacity, and is sealed to IP67, making it suitable for use in engine compartments and bilge area applications. Built with a thermoset plastic housing (UL rated 94V0, 311°F / 155°C) and corrosion-resistant hardware including tin plated copper studs, brass rivets, and stainless steel locking nuts, it is ideal for auxiliary and accessory circuits in trucks, buses, RVs, marine systems, battery chargers, and DC audio systems. Terminal stud torque is 50 in-lb (5.6 Nm) max, operating temperature range is -25°F (-32°C) to 180°F (82°C), and storage temperature range is -30°F (-34°C) to 300°F (149°C).
- Description
- Ask a Question
-
BEP 185040F-01-1 – 184 & 185 Series Switchable Reset Thermal Circuit Breaker 40A, Surface Mount, IP67, 30V DC
The BEP 185040F-01-1 is a heavy-duty single pole thermal circuit breaker from the BEP 184 & 185 Series, engineered for reliable DC circuit protection in demanding marine and vehicle environments. This model features a switchable reset mechanism that can be manually operated to isolate the circuit and provides a visible indication of the tripped condition.
Rated at 40A and designed for systems up to 30V DC, the breaker offers a 3000A interrupt capacity. With IP67 sealing, it is well-suited for installations where protection against water and dust ingress is required, including engine compartment and bilge area applications.
Key Features
- Part number: 185040F-01-1
- Series: 184 & 185
- Breaker type: Heavy-duty single pole thermal circuit breaker
- Reset mechanism: Switchable reset with visible trip indication
- Rated current: 40A
- Rated voltage: 30V DC
- Interrupt capacity: 3000A
- Ingress protection: IP67
- Mounting: Surface mount
Applications
- Auxiliary and accessory circuits in trucks and buses
- RV electrical systems
- Marine electrical installations
- Battery chargers
- DC audio systems
Construction & Materials
- Housing: Thermoset plastic
- Housing rating: UL rated 94V0
- Housing temperature rating: 311°F (155°C)
- Stud insulators provided on covered units with F (Surface Mount) bases
- Hardware includes tin plated copper studs, brass rivets, and stainless steel locking nuts
Temperature Ratings
Parameter Value Operating Temperature -25°F (-32°C) to 180°F (82°C) Storage Temperature -30°F (-34°C) to 300°F (149°C)
Electrical & Installation Specifications
Specification Value Rated Current 40A Rated Voltage 30V DC Interrupt Capacity 3000A Terminal Stud Torque (Max.) 50 in-lb (5.6 Nm) Ingress Protection IP67
Approvals
- Complies with SAEJ1625
- Complies with J1171
- Complies with UL1500 (Ignition protected) specifications
-
