The BEP 185060P-01-1 is a heavy-duty single pole thermal type circuit breaker rated at 60A for 30V DC systems, designed for panel mount (flush mount) installation with a switchable reset mechanism that can be manually switched to isolate the circuit. It provides 3000A interrupt capacity, a unique reset mechanism with visible trip indication, and is sealed for demanding installations such as engine compartments and bilge areas. Built for auxiliary and accessory circuits in marine, trucks, buses, and RVs, it also suits battery chargers and DC audio systems, with IP67 ingress protection, operating temperature of -25°F (-32°C) to 180°F (82°C), and compliance with SAEJ1625, J1171, and UL1500 (Ignition protected).
- Description
- Ask a Question
-
BEP 185060P-01-1 – HD Thermal Circuit Breaker 60A, Switchable Reset, Panel Mount (Flush), 30V DC, IP67
The BEP 185060P-01-1 is a heavy-duty single pole thermal type circuit breaker designed to protect auxiliary and accessory circuits in demanding 30V DC electrical systems. Rated at 60A, this breaker is engineered for use across marine and vehicle applications where durable circuit protection is required.
This model is a switchable reset breaker that can be manually switched to isolate the circuit. Series 184 & 185 breakers incorporate a unique reset mechanism providing visible indication of a tripped condition.
Key Features
- Product Number: 185060P-01-1
- Type: Heavy-duty single pole thermal type breaker
- Rated Current: 60A
- Rated Voltage: 30V DC
- Interrupt Capacity: 3000A
- Reset Type: Switchable Reset (manual switching available)
- Mounting: Panel mount (flush mount)
- Terminal Stud Torque: 50 in-lb (5.6Nm) max.
- Ingress Protection Rating: IP67
Applications
- Auxiliary and accessory circuits
- Trucks, buses, RVs, and marine environments
- Battery chargers
- DC audio systems
- Engine compartment and bilge area applications (sealed series)
Temperature Ranges
- Operating Temperature: -25°F (-32°C) to 180°F (82°C)
- Storage Temperature: -30°F (-34°C) to 300°F (149°C)
Construction
- Housing: Thermoset plastic
- UL Rating: 94V0
- Material Temperature Rating: 311°F (155°C)
- Hardware: Tin plated copper studs, brass rivets, stainless steel locking nuts
- Stud Insulators: Provided on covered units with surface mount bases
Approvals
- Complies with SAEJ1625
- Complies with J1171
- Complies with UL1500 (Ignition protected)
Product Summary
Specification Value Model BEP 185060P-01-1 Rated Current 60A Rated Voltage 30V DC Mounting Type Panel Mount (Flush Mount) Reset Type Switchable Reset Interrupt Capacity 3000A Ingress Protection IP67 Terminal Stud Torque (Max.) 50 in-lb (5.6Nm) -
