The BEP 185030F-01-1 is a heavy-duty single pole thermal type circuit breaker rated at 30A for 30V DC systems, built in a switchable reset version that can be manually switched to isolate the circuit. Designed for surface mount installation, it provides 3000A interrupt capacity, IP67 ingress protection, and compliance with SAEJ1625, J1171, and UL1500 (Ignition protected) specifications. The breaker is suitable for auxiliary and accessory circuits in marine applications, including sealed use in engine compartments and bilge areas, and operates from -25°F (-32°C) to 180°F (82°C).
- Description
- Ask a Question
-
BEP 185030F-01-1 – HD Thermal Circuit Breaker 30A, Switchable Reset, Surface Mount, 30V DC, IP67
The BEP 185030F-01-1 is a heavy-duty single pole thermal type circuit breaker designed to provide reliable circuit protection in demanding 30V DC electrical systems. Rated at 30A, this breaker is suitable for auxiliary and accessory circuits across marine and vehicle applications.
This model is a switchable reset breaker that can be manually switched to isolate the circuit. Series 184 & 185 breakers feature a unique reset mechanism providing visible indication of a tripped condition.
Key Features
- Product Number: 185030F-01-1
- Type: Single Pole Thermal Type Circuit Breaker
- Rated Current: 30A
- Rated Voltage: 30V DC
- Interrupt Capacity: 3000A
- Reset Type: Switchable Reset (manual switching to isolate the circuit)
- Mounting: Surface mount
- Ingress Protection Rating: IP67
- Terminal Stud Torque: 50 in-lb (5.6Nm) max.
Temperature Ranges
- Operating Temperature: -25°F (-32°C) to 180°F (82°C)
- Storage Temperature: -30°F (-34°C) to 300°F (149°C)
Applications
- Auxiliary and accessory circuits
- Marine electrical applications
- Trucks, buses, and RV applications
- Battery chargers
- DC audio systems
- Engine compartment and bilge area installations (sealed series 184 & 185)
Construction
- Housing: Thermoset plastic
- UL Rating: 94V0
- Material Temperature Rating: 311°F (155°C)
- Hardware: Tin plated copper studs, brass rivets, stainless steel locking nuts
Approvals
- Complies with SAEJ1625
- Complies with J1171
- Complies with UL1500 (Ignition protected)
Product Summary
Specification Value Model BEP 185030F-01-1 Rated Current 30A Rated Voltage 30V DC Mounting Type Surface Mount Reset Type Switchable Reset Interrupt Capacity 3000A Ingress Protection IP67 -
