ID
1310541
$ 95.89
1-2 weeks delivery time
-
+
The BEP 185050F/DSP is a heavy-duty single pole thermal type circuit breaker rated at 50A for 30V DC systems, designed with a switchable reset mechanism that can be manually switched to isolate the circuit. Built for surface mount installation, it offers 3000A interrupt capacity, IP67 ingress protection, and a unique reset mechanism providing visible indication of a tripped condition. Suitable for auxiliary and accessory circuits in marine and vehicle installations, it is designed for use in sealed environments such as engine compartments and bilge areas, with an operating temperature range of -25°F (-32°C) to 180°F (82°C).
- Description
- Ask a Question
-
BEP 185050F/DSP – HD Thermal Circuit Breaker 50A, Switchable Reset, Surface Mount, 30V DC, IP67
The BEP 185050F/DSP is a heavy-duty single pole thermal type circuit breaker designed for reliable protection of auxiliary and accessory circuits in 30V DC electrical systems. With a rated current of 50A, it is suitable for demanding marine and vehicle applications where robust circuit protection is required.
This model features a switchable reset mechanism that can be manually switched to isolate the circuit. Series 184 & 185 breakers include a unique reset mechanism providing a visible indication of a tripped condition.
Key Features
- Model: BEP 185050F/DSP
- Type: Single Pole Thermal Type Circuit Breaker
- Rated Current: 50A
- Rated Voltage: 30V DC
- Interrupt Capacity: 3000A
- Reset Type: Switchable Reset (manual switching available)
- Mounting: Surface mount
- Ingress Protection Rating: IP67
- Terminal Stud Torque: 50 in-lb (5.6Nm) max.
Temperature Ranges
- Operating Temperature: -25°F (-32°C) to 180°F (82°C)
- Storage Temperature: -30°F (-34°C) to 300°F (149°C)
Applications
- Auxiliary and accessory circuits
- Marine applications
- Trucks, buses, and RV applications
- Battery chargers and DC audio systems
- Engine compartment and bilge area installations (sealed Series 184 & 185)
Construction
- Housing: Thermoset plastic
- UL Rating: 94V0
- Material Temperature Rating: 311°F (155°C)
- Hardware: Tin plated copper studs, brass rivets, stainless steel locking nuts
Approvals
- Complies with SAEJ1625
- Complies with J1171
- Complies with UL1500 (Ignition protected)
Product Summary
Specification Value Model BEP 185050F/DSP Rated Current 50A Rated Voltage 30V DC Mounting Type Surface Mount Reset Type Switchable Reset Interrupt Capacity 3000A Ingress Protection IP67 -
