ID
1323343
$ 105.15
1-2 weeks delivery time
-
+
The BEP 185050P/DSP is a heavy-duty single pole thermal type circuit breaker rated at 50A for 30V DC systems, featuring a switchable reset mechanism that can be manually switched to isolate the circuit. Designed for panel mount (flush mount) installation, it provides 3000A interrupt capacity, IP67 ingress protection, and a unique reset mechanism with visible indication of a tripped condition. Suitable for auxiliary and accessory circuits in marine and vehicle applications, it is designed for sealed use in engine compartments and bilge areas, with an operating temperature range of -25°F (-32°C) to 180°F (82°C).
- Description
- Ask a Question
-
BEP 185050P/DSP – HD Thermal Circuit Breaker 50A, Switchable Reset, Panel Mount (Flush), 30V DC, IP67
The BEP 185050P/DSP is a heavy-duty single pole thermal type circuit breaker designed for panel mount (flush mount) installation. Rated at 50A for 30V DC systems, it provides dependable circuit protection for auxiliary and accessory circuits in demanding marine and vehicle applications.
This breaker features a switchable reset mechanism that can be manually switched to isolate the circuit. Series 184 & 185 breakers include a unique reset mechanism providing visible indication of a tripped condition.
Key Features
- Model: BEP 185050P/DSP
- Type: Single Pole Thermal Type Circuit Breaker
- Rated Current: 50A
- Rated Voltage: 30V DC
- Interrupt Capacity: 3000A
- Reset Type: Switchable Reset (manual switching available)
- Mounting: Panel mount (flush mount)
- Ingress Protection Rating: IP67
- Terminal Stud Torque: 50 in-lb (5.6Nm) max.
Temperature Ranges
- Operating Temperature: -25°F (-32°C) to 180°F (82°C)
- Storage Temperature: -30°F (-34°C) to 300°F (149°C)
Applications
- Auxiliary and accessory circuits
- Marine applications
- Trucks, buses, RVs, and marine electrical systems
- Battery chargers and DC audio systems
- Engine compartment and bilge area applications (sealed Series 184 & 185)
Construction
- Housing: Thermoset plastic
- UL Rating: 94V0
- Material Temperature Rating: 311°F (155°C)
- Hardware: Tin plated copper studs, brass rivets, stainless steel locking nuts
Approvals
- Complies with SAEJ1625
- Complies with J1171
- Complies with UL1500 (Ignition protected)
Product Summary
Specification Value Model BEP 185050P/DSP Rated Current 50A Rated Voltage 30V DC Mounting Type Panel Mount (Flush Mount) Reset Type Switchable Reset Interrupt Capacity 3000A Ingress Protection IP67 -
