The BEP 185100P-01-1 is a heavy-duty single pole thermal circuit breaker rated at 100A (30V DC) with a switchable reset mechanism and panel mount (flush mount) installation. It provides 3000A interrupt capacity, IP67 protection, and visible trip indication for marine and vehicle auxiliary circuits.
- Description
- Ask a Question
-
BEP 185100P-01-1 – HD Thermal Circuit Breaker 100A, Switchable Reset, Panel Mount (Flush), 30V DC, IP67
The BEP 185100P-01-1 is a heavy-duty single pole thermal type circuit breaker designed for reliable protection of auxiliary and accessory circuits in demanding 30V DC electrical systems. With a rated current of 100A, it is suitable for use across trucks, buses, RVs, and marine installations.
This model features a switchable reset mechanism that can be manually switched to isolate the circuit. A unique reset mechanism provides visible indication of a tripped condition, supporting safer operation and simpler troubleshooting.
Key Features
- Product Number: 185100P-01-1
- Type: Heavy-duty single pole thermal type breaker
- Rated Current: 100A
- Rated Voltage: 30V DC
- Interrupt Capacity: 3000A
- Reset Type: Switchable Reset
- Mounting: Panel mount (flush mount)
- Terminal Stud Torque: 50 in-lb (5.6Nm) max.
- Ingress Protection Rating: IP67
Applications
- Auxiliary and accessory circuits
- Trucks, buses, RVs, and marine applications
- Battery chargers
- DC audio systems
- Engine compartment and bilge area applications (sealed series)
Temperature Ranges
- Operating Temperature: -25°F (-32°C) to 180°F (82°C)
- Storage Temperature: -30°F (-34°C) to 300°F (149°C)
Construction
- Housing: Thermoset plastic
- UL Rating: 94V0
- Material Temperature Rating: 311°F (155°C)
- Hardware: Tin plated copper studs, brass rivets, stainless steel locking nuts
- Stud Insulators: Provided on covered units with F (Surface Mount) bases
Approvals
- Complies with SAEJ1625
- Complies with J1171
- Complies with UL1500 (Ignition protected)
Product Summary
Specification Value Model BEP 185100P-01-1 Rated Current 100A Rated Voltage 30V DC Mounting Type Panel Mount (Flush Mount) Reset Type Switchable Reset Interrupt Capacity 3000A Ingress Protection IP67 -
