The BEP 185150F/DSP is a heavy-duty single pole thermal circuit breaker rated at 150A (30V DC) for surface mount installation. It features a switchable reset design with visible trip indication, 3000A interrupt capacity, and IP67 protection for reliable use in marine and vehicle auxiliary circuits.
- Description
- Ask a Question
-
BEP 185150F/DSP – HD Thermal Circuit Breaker 150A, Switchable Reset, Surface Mount, 30V DC, IP67
The BEP 185150F/DSP is a heavy-duty single pole thermal type circuit breaker designed to protect auxiliary and accessory circuits in demanding environments. Rated at 150A and 30V DC, it is suitable for applications in trucks, buses, RVs, and marine electrical systems, including battery chargers and DC audio installations.
This model features a switchable reset mechanism that can be manually switched to isolate the circuit. Series 184 and 185 breakers include a unique reset design that provides visible indication of a tripped condition, supporting safer operation and faster troubleshooting.
Key Features
- Model: BEP 185150F/DSP
- Type: Heavy-duty single pole thermal circuit breaker
- Rated Current: 150A
- Rated Voltage: 30V DC
- Interrupt Capacity: 3000A
- Reset Type: Switchable Reset
- Mounting: Surface mount
- Terminal Stud Torque: 50 in-lb (5.6Nm) max.
- Ingress Protection Rating: IP67
Applications
- Auxiliary and accessory circuits
- Trucks, buses and RV electrical systems
- Marine electrical installations
- Battery chargers
- DC audio systems
- Engine compartment and bilge area applications (sealed series)
Temperature Ranges
- Operating Temperature: -25°F (-32°C) to 180°F (82°C)
- Storage Temperature: -30°F (-34°C) to 300°F (149°C)
Construction
- Housing: Thermoset plastic
- UL Rating: 94V0
- Material Temperature Rating: 311°F (155°C)
- Hardware: Tin plated copper studs, brass rivets, stainless steel locking nuts
- Stud Insulators: Provided on covered units with surface mount bases
Approvals
- Complies with SAEJ1625
- Complies with J1171
- Complies with UL1500 (Ignition protected)
Product Summary
Specification Value Model BEP 185150F/DSP Rated Current 150A Rated Voltage 30V DC Mounting Type Surface Mount Reset Type Switchable Reset Interrupt Capacity 3000A Ingress Protection IP67 -
