The BEP 185100P/DSP is a heavy-duty single pole thermal circuit breaker rated at 100A (30V DC) with a switchable reset mechanism and panel mount (flush mount) installation. It provides 3000A interrupt capacity, IP67 protection, and visible trip indication for demanding marine and vehicle auxiliary circuits.
- Description
- Ask a Question
-
BEP 185100P/DSP – HD Thermal Circuit Breaker 100A, Switchable Reset, Panel Mount (Flush), 30V DC, IP67
The BEP 185100P/DSP is a heavy-duty single pole thermal type circuit breaker designed for reliable circuit protection in 30V DC electrical systems. With a rated current of 100A, it is intended for auxiliary and accessory circuits in trucks, buses, RVs, and marine applications, including use with battery chargers and DC audio systems.
This model features a switchable reset mechanism that can be manually switched to isolate the circuit. A unique reset mechanism provides visible indication of a tripped condition, supporting fast troubleshooting and safer operation.
Key Features
- Model: BEP 185100P/DSP
- Type: Heavy-duty single pole thermal type breaker
- Rated Current: 100A
- Rated Voltage: 30V DC
- Interrupt Capacity: 3000A
- Reset Type: Switchable Reset
- Mounting: Panel mount (flush mount)
- Terminal Stud Torque: 50 in-lb (5.6Nm) max.
- Ingress Protection Rating: IP67
Applications
- Auxiliary and accessory circuits
- Trucks, buses, RVs and marine applications
- Battery chargers
- DC audio systems
- Engine compartment and bilge area applications (sealed series)
Temperature Ranges
- Operating Temperature: -25°F (-32°C) to 180°F (82°C)
- Storage Temperature: -30°F (-34°C) to 300°F (149°C)
Construction
- Housing: Thermoset plastic
- UL Rating: 94V0
- Material Temperature Rating: 311°F (155°C)
- Hardware: Tin plated copper studs, brass rivets, stainless steel locking nuts
- Stud Insulators: Provided on covered units with surface mount bases
Approvals
- Complies with SAEJ1625
- Complies with J1171
- Complies with UL1500 (Ignition protected)
Product Summary
Specification Value Model BEP 185100P/DSP Rated Current 100A Rated Voltage 30V DC Mounting Type Panel Mount (Flush Mount) Reset Type Switchable Reset Interrupt Capacity 3000A Ingress Protection IP67 -
