The BEP 185135P/DSP is a heavy-duty single pole thermal circuit breaker rated at 135A (30V DC) with switchable reset and panel mount (flush mount) installation. It offers 3000A interrupt capacity, IP67 protection, and visible trip indication for marine and vehicle auxiliary circuits.
- Description
- Ask a Question
-
BEP 185135P/DSP – HD Thermal Circuit Breaker 135A, Switchable Reset, Panel Mount (Flush), 30V DC, IP67
The BEP 185135P/DSP is a heavy-duty single pole thermal type circuit breaker designed for reliable circuit protection in demanding 30V DC installations. With a rated current of 135A, it is intended for auxiliary and accessory circuits used in trucks, buses, RVs, and marine applications, including battery chargers and DC audio systems.
This breaker features a switchable reset mechanism that can be manually switched to isolate the circuit. A unique reset mechanism provides visible indication of a tripped condition for improved safety and simplified troubleshooting.
Key Features
- Model: BEP 185135P/DSP
- Type: Heavy-duty single pole thermal type breaker
- Rated Current: 135A
- Rated Voltage: 30V DC
- Interrupt Capacity: 3000A
- Reset Type: Switchable Reset
- Mounting: Panel mount (flush mount)
- Terminal Stud Torque: 50 in-lb (5.6Nm) max.
- Ingress Protection Rating: IP67
Applications
- Auxiliary and accessory circuits
- Trucks, buses, RVs and marine applications
- Battery chargers
- DC audio systems
- Engine compartment and bilge area applications (sealed series)
Temperature Ranges
- Operating Temperature: -25°F (-32°C) to 180°F (82°C)
- Storage Temperature: -30°F (-34°C) to 300°F (149°C)
Construction
- Housing: Thermoset plastic
- UL Rating: 94V0
- Material Temperature Rating: 311°F (155°C)
- Hardware: Tin plated copper studs, brass rivets, stainless steel locking nuts
- Stud Insulators: Provided on covered units with surface mount bases
Approvals
- Complies with SAEJ1625
- Complies with J1171
- Complies with UL1500 (Ignition protected)
Product Summary
Specification Value Model BEP 185135P/DSP Rated Current 135A Rated Voltage 30V DC Mounting Type Panel Mount (Flush Mount) Reset Type Switchable Reset Interrupt Capacity 3000A Ingress Protection IP67 -
