The BEP 185120P-01-1 is a heavy-duty single pole thermal circuit breaker rated at 120A (30V DC) with switchable reset operation and panel mount (flush mount) installation. It provides 3000A interrupt capacity, IP67 protection, and visible trip indication for marine and vehicle auxiliary circuits.
- Description
- Ask a Question
-
BEP 185120P-01-1 – HD Thermal Circuit Breaker 120A, Switchable Reset, Panel Mount (Flush), 30V DC, IP67
The BEP 185120P-01-1 is a heavy-duty single pole thermal type circuit breaker engineered for reliable circuit protection in demanding 30V DC systems. With a rated current of 120A, it is designed for auxiliary and accessory circuits used in trucks, buses, RVs, and marine applications, including battery chargers and DC audio systems.
The breaker features a switchable reset mechanism that can be manually switched to isolate the circuit. A unique reset mechanism provides visible indication of a tripped condition for safer operation and easier fault identification.
Key Features
- Product Number: 185120P-01-1
- Type: Heavy-duty single pole thermal type breaker
- Rated Current: 120A
- Rated Voltage: 30V DC
- Interrupt Capacity: 3000A
- Reset Type: Switchable Reset
- Mounting: Panel mount (flush mount)
- Terminal Stud Torque: 50 in-lb (5.6Nm) max.
- Ingress Protection Rating: IP67
Applications
- Auxiliary and accessory circuits
- Trucks, buses, RVs and marine applications
- Battery chargers
- DC audio systems
- Engine compartment and bilge area applications (sealed series)
Temperature Ranges
- Operating Temperature: -25°F (-32°C) to 180°F (82°C)
- Storage Temperature: -30°F (-34°C) to 300°F (149°C)
Construction
- Housing: Thermoset plastic
- UL Rating: 94V0
- Material Temperature Rating: 311°F (155°C)
- Hardware: Tin plated copper studs, brass rivets, stainless steel locking nuts
- Stud Insulators: Provided on covered units with surface mount bases
Approvals
- Complies with SAEJ1625
- Complies with J1171
- Complies with UL1500 (Ignition protected)
Product Summary
Specification Value Model BEP 185120P-01-1 Rated Current 120A Rated Voltage 30V DC Mounting Type Panel Mount (Flush Mount) Reset Type Switchable Reset Interrupt Capacity 3000A Ingress Protection IP67 -
