ID
1282087
$ 4,701.04
1-2 weeks delivery time
-
+
The Vetus P102774 – Maxwell 1000 VW is a hydraulic vertical anchor windlass with integrated warping drum and 150 TDC configuration, designed for rope and chain combination anchor rodes. Intended for sailing boats with limited anchor locker space, this hydraulic model supports manual rope-to-chain transfer, controlled free-fall anchoring, and reliable handling of 6–10 mm short link chain in compact marine installations.
- Description
- Ask a Question
-
Vetus P102774 – Maxwell 1000 VW Hydraulic Vertical Anchor Windlass with Drum
The Maxwell 1000 VW hydraulic anchor windlass is part of the VW Series, developed for traditional rope and chain combination anchor rodes where manual transfer of the rode from the rope warping drum to the chainwheel is required. The 150TDC configuration provides increased deck clearance while retaining a compact vertical layout suitable for sailing boats with limited space inside the anchor locker.
Specification Value Product Code Vetus P102774 Series Maxwell VW Series Drive Type Hydraulic Windlass Orientation Vertical Rode Type Rope / Chain Combination Warping Drum Yes Total Deck Clearance (TDC) 150 mm Weight 22 kg Maximum Pull / Lift 700 kg Short Link Chain Size 6 – 10 mm Standard Chain Size 6 – 8 mm
Design and Functional Features
- Designed for traditional rope and chain anchor rodes with manual transfer between drum and chainwheel
- Provides versatility to operate two anchors from a single windlass
- Independent MAX-grip™ warping drum enables rope hauling from any direction
- Chainwheel clutch disengagement allows positive control of all ropes
- Permits the use of traditional shackle and thimble rope-to-chain connections
Construction and Materials
- Above-deck components manufactured from marine-grade stainless steel (AISI 316)
- Chromed bronze components for enhanced corrosion resistance and durability
- Anodized aluminium gearbox and spacer for reduced weight and long service life
- Marine-grade stainless steel (AISI 316) fasteners for secure through-deck installation
Operational and Installation Details
- Cone-type brake and clutch mechanism enables controlled manual free-fall anchoring
- Smooth, progressive clutch engagement ensures safe and precise operator control
- Chainwheel locking pawl included (except on VW500 and VW10 models)
- Hydraulic drive system designed specifically for marine winch applications
- Modular construction simplifies installation and ensures precise gearbox alignment
- Allows alternative horizontal mounting on a fore-and-aft bulkhead for below-deck installation
- Windlass can be easily disassembled for servicing and routine maintenance
-
