ID
1282131
$ 5,049.24
1-2 weeks delivery time
-
+
The Maxwell VWCLP 1000 anchor windlass (article Vetus P100417) is a vertical 12V electric windlass with a 1000W motor, designed for automatic handling of chain-only anchor rodes. Featuring a low-profile configuration without warping drum and a 50TDC clockwise (CW) chainwheel, it supports 6–10 mm chain, delivers a maximum pull of 700 kg, weighs 24 kg, and is optimized for compact installations requiring reliable automatic chain handling and controlled free-fall anchoring.
- Description
- Ask a Question
-
Maxwell VWCLP 1000 Vertical Anchor Windlass 12V 1000W 50TDC CW (Vetus P100417)
The Maxwell VWCLP Series 1000 is engineered for automatic vertical handling of chain-only anchor rodes in applications where minimal above-deck height is required. This low-profile configuration is supplied without a warping drum, providing a compact solution while maintaining fully automatic chainwheel operation. The 50TDC clockwise (CW) chainwheel offers reduced deck clearance, making this model suitable for vessels with limited anchor locker space.
Design and Functional Features
- Designed for automatic vertical handling of chain-only anchor rodes
- Low-profile (LP) configuration without warping drum
- Clockwise (CW) anchor retrieval configuration
- Fully automatic single or dual direction chainwheel operation
- Integral chain pipe and stripper aligned for virtually jam-free chain handling
- Chainwheel locking pawl for secure anchoring operation
Construction and Materials
- Above-deck components manufactured from marine-grade stainless steel (AISI 316)
- Anodized aluminium gearbox and spacer tube for corrosion resistance
- Heavy-duty, dual-direction electric motor designed for marine winch applications
- Marine-grade stainless steel fasteners ensuring precise alignment of gearbox and topworks
Brake and Control System
- Cone-type brake and clutch mechanism permitting manual free-fall anchoring
- Smooth progressive clutch engagement ensuring safe and precise operator control
- Chainwheel locking pawl for controlled and secure anchoring
Installation and Maintenance
- Simple through-deck installation enabled by modular design
- Precision alignment of gearbox to topworks for reliable long-term operation
- Easily disassembled construction for servicing and routine maintenance
- Optimized for installations requiring reduced above-deck height
Technical Specifications
Parameter Specification Motor Power 1000 W Operating Voltage 12 V Configuration Vertical Rode Type Chain Warping Drum No Chainwheel Type 50TDC CW Maximum Pull / Lift 700 kg Supported Chain Size 6 – 10 mm Short Link Chain Size 6 – 10 mm Weight 24 kg -
