ID
675774
$ 25.72
1-2 weeks delivery time
Type:
- Up
- Down
Item:
- Plastic
- RVS
The Italwinch Windlass Foot Switch series provides safe and convenient foot-operated control for electric anchor windlasses on 12V and 24V systems. Available in Up and Down versions with either a thermoplastic or AISI stainless steel protective cover, these switches feature a marine-grade stainless steel base, seawater-resistant silicone rubber button, and an anti-shock safety cover to prevent accidental activation. Delivered fully assembled, they are designed for reliable operation in demanding marine environments.
- Description
- Ask a Question
-
Italwinch Windlass Foot Switches 12/24V – Up & Down, Thermoplastic or Stainless Steel Cover
The Italwinch Windlass Foot Switch range is designed to provide reliable and convenient foot-operated control of electric anchor windlasses. Suitable for both 12V and 24V DC systems, these marine switches are available in Up and Down configurations with either a durable thermoplastic or AISI stainless steel protective cover.
Each switch features a corrosion-resistant stainless steel mounting base, a seawater-resistant silicone rubber push button, and an anti-shock protective cover that helps prevent accidental operation. The switches are compatible with MZ Electronic control boxes and any normally open relay contact, making them suitable for both new installations and replacement applications.
Supplied fully assembled and ready for installation, the Italwinch Foot Switch series offers dependable long-term performance for yachts, motorboats and commercial vessels operating in demanding marine environments.
Key Features
- Foot-operated control for electric anchor windlasses
- Available in Up and Down versions
- Suitable for 12V and 24V DC systems
- Choice of thermoplastic or AISI stainless steel protective cover
- Marine-grade stainless steel mounting base
- Seawater-resistant silicone rubber push button
- Anti-shock safety cover prevents accidental activation
- Compatible with MZ Electronic control boxes and normally open relays
- Fully assembled for quick installation
- Designed for long-term marine use
Technical Specifications
Specification Details Product Type Windlass Foot Switch Manufacturer Italwinch / MZ Electronic Supply Voltage 12 / 24 V DC Maximum Current 5 A Maximum Load 4 A Switch Type Normally Open (NO) Base Material Marine-grade Stainless Steel Button Material Seawater-resistant Silicone Rubber Protective Cover Thermoplastic or AISI Stainless Steel Dimensions (AISI versions) 75 × 16 × 88 mm Installation Deck mounted
Available Versions
- Down – Thermoplastic Cover – Italwinch FOSWI210BIS – VDM/Reya 284047
- Up – Thermoplastic Cover – Italwinch FOSWI220BIS – VDM/Reya 284048
- Down – AISI Stainless Steel Cover – Italwinch FOSWI110-AISI – VDM/Reya 601469
- Up – AISI Stainless Steel Cover – Italwinch FOSWI120-AISI – VDM/Reya 601470
Applications
- Electric anchor windlasses
- Yachts and sailing boats
- Motorboats
- Commercial marine vessels
- Replacement or new windlass installations
Documents
Italwinch Windlass Foot Switch Size: 304,3 Kb -
