The Italwinch CC011 Wired Chain Counter is a compact digital display designed to accurately monitor the deployed anchor chain length on electric windlass systems. Compatible with virtually all windlass types, it measures chain length in meters or feet while providing a clear real-time readout. Operating on 9–30V DC, the CC011 features an IP65-rated housing, compact flush-mount design, and low power consumption, making it an ideal monitoring solution for modern marine anchoring systems. This unit functions exclusively as a chain counter display and does not control the windlass motor.
- Description
- Ask a Question
-
Italwinch CC011 Wired Chain Counter Display 9–30V IP65 for Electric Windlasses
The Italwinch CC011 is a compact wired chain counter designed to provide precise monitoring of anchor chain deployment on electric windlass systems. Suitable for installation on virtually all types of windlasses, it displays the deployed chain length in real time, allowing the operator to anchor more accurately and safely.
The CC011 features a flush-mounted round display with a compact footprint, operates on 9–30V DC, and is protected by an IP65-rated enclosure for dependable performance in demanding marine environments. The display can be configured to show chain length in either meters or feet. Designed purely as a monitoring device, the CC011 does not provide windlass control functions.
Key Features
- Original Italwinch CC011 wired chain counter display
- Compatible with most electric windlass systems
- Accurate chain length measurement
- Displays chain length in meters or feet
- Compact round flush-mount design
- Simple installation
- Low power consumption
- IP65 protection against water and dust
- Designed exclusively for chain monitoring (no windlass control)
Technical Specifications
Specification Value Product Type Wired Chain Counter Display Operating Voltage 9–30V DC Display Function Chain Length Measurement Measurement Units Meters or Feet Protection Rating IP65 Current Consumption 100 mA Dimensions 66 × 60 mm Weight 150 g Installation Flush Mount Windlass Control No (Display Only) Manufacturer Italwinch
Applications
- Electric anchor windlasses
- Anchor chain monitoring systems
- Yachts and motorboats
- Commercial marine vessels
- Retrofit chain counter installations
Note: The CC011 functions solely as a chain counter display. It measures and displays deployed chain length but does not operate or control the windlass itself.
-
