Osculati Marine Electrical Cable IEC 60332-3-22 – Single Core, 100 m Roll

ID 1377048

$ 89.65

1-2 weeks delivery time

Type:

1.5 mm²
2.5 mm²
4 mm²
6 mm²

Color:

Blue
Red
Black
White
Grey
Brown
Yellow/Green

The Osculati Marine Electrical Cable IEC 60332-3-22 is a single-core copper cable with extra-insulating PVC sheath, designed for marine electrical systems and compliant with CEI 20-22 II, CEI 20-371 and EU Directive 2011/95/CE. Flame-retardant and oil-resistant, it is suitable for bilges and engine-room installations. Available in multiple conductor colors and cross-sections from 1.5 mm² to 6 mm², supplied in 100 m rolls.

Description
Ask a Question

Osculati Marine Electrical Cable IEC 60332-3-22 – Single Core, 1.5–6 mm², 100 m Roll

The Osculati Marine Electrical Cable is manufactured from copper conductors with an extra-insulating PVC sheath for dependable performance in marine electrical installations. Designed according to IEC 60332-3-22 requirements, the cable is flame-retardant and oil-resistant, making it suitable for use in bilges, machinery spaces, electrical panels, lighting systems, pumps, navigation equipment and general onboard wiring.

Manufactured in compliance with CEI 20-22 II and CEI 20-371 standards and meeting EU Directive 2011/95/CE requirements.

Key Features

Single-core marine electrical cable
Copper conductor
Extra-insulating PVC sheath
IEC 60332-3-22 compliant
Flame-retardant construction
Oil-resistant insulation
Suitable for bilge and engine-room installations
Available in multiple conductor colors
Supplied in 100 m rolls

Available Variations

Cross Section	Color	Osculati Code	Roll Length
1.5 mm²	White	14.150.15BI	100 m
1.5 mm²	Blue	14.150.15BL	100 m
1.5 mm²	Grey	14.150.15GR	100 m
1.5 mm²	Yellow/Green	14.150.15GV	100 m
1.5 mm²	Brown	14.150.15MA	100 m
1.5 mm²	Black	14.150.15NE	100 m
1.5 mm²	Red	14.150.15RO	100 m
2.5 mm²	White	14.150.25BI	100 m
2.5 mm²	Blue	14.150.25BL	100 m
2.5 mm²	Yellow/Green	14.150.25GV	100 m
2.5 mm²	Black	14.150.25NE	100 m
2.5 mm²	Red	14.150.25RO	100 m
4 mm²	Blue	14.150.40BL	100 m
4 mm²	Yellow/Green	14.150.40GV	100 m
4 mm²	Black	14.150.40NE	100 m
4 mm²	Red	14.150.40RO	100 m
6 mm²	Blue	14.150.60BL	100 m
6 mm²	Yellow/Green	14.150.60GV	100 m
6 mm²	Black	14.150.60NE	100 m
6 mm²	Red	14.150.60RO	100 m

Technical Specifications

Brand	Osculati
Conductor Material	Copper
Insulation Material	Extra-Insulating PVC
Cable Type	Single Core
Standard	IEC 60332-3-22
Compliance	CEI 20-22 II, CEI 20-371, EU Directive 2011/95/CE
Properties	Flame Retardant, Oil Resistant
Roll Length	100 m

Sold individually in the selected cross-section and conductor color.
