ID
1377040
$ 198
1-2 weeks delivery time
Type:
- 1.5 mm²
- 2.5 mm²
- 4 mm²
Color:
- Black/White/Blue
- Black/Brown/Red
- Blue/Yellow-Green/Black
The Osculati Marine Tripolar Electrical Cable is manufactured from copper conductors with an extra-insulating PVC sheath and complies with IEC 60332-3-22, CEI 20-22 II, CEI 20-371 and EU Directive 2011/95/CE. Flame-retardant and oil-resistant, it is designed for marine electrical installations, bilges and engine-room applications. Available in standard tripolar and bilge pump configurations with conductor cross-sections from 1.5 mm² to 4 mm², supplied in 50 m rolls.
- Description
- Ask a Question
-
Osculati Marine Tripolar Electrical Cable IEC 60332-3-22 – 1.5–4 mm², 50 m Roll
The Osculati Marine Tripolar Electrical Cable is designed for professional marine electrical systems requiring three conductors within a single protective sheath. Manufactured from copper conductors and protected by an extra-insulating PVC outer jacket, this cable offers excellent durability and resistance in demanding onboard environments.
Complying with IEC 60332-3-22, CEI 20-22 II, CEI 20-371 and EU Directive 2011/95/CE, the cable is flame-retardant and oil-resistant, making it suitable for use in bilges, engine compartments, lighting circuits, control systems, pumps and other marine electrical applications.
Key Features
- Tripolar marine electrical cable
- Copper conductors
- Extra-insulating PVC sheath
- Flame-retardant construction
- Oil-resistant insulation
- Suitable for bilges and engine-room installations
- Available in standard and bilge pump conductor configurations
- Supplied in 50 m rolls
- IEC 60332-3-22 compliant
Available Variations
Osculati Code Version Wire Colours Cross Section External Ø Roll Length 14.147.15 Tripolar Black / White / Blue 1.5 mm² 8.5 mm 50 m 14.147.25 Tripolar Black / White / Blue 2.5 mm² 10.9 mm 50 m 14.149.10 Tripolar (Bilge Pumps) Black / Brown / Red 1.5 mm² 8.2 mm 50 m 14.149.20 Tripolar (Bilge Pumps) Black / Brown / Red 2.5 mm² 9.2 mm 50 m 14.146.15 Tripolar Blue / Yellow-Green / Black 1.5 mm² 8.5 mm 50 m 14.146.25 Tripolar Blue / Yellow-Green / Black 2.5 mm² 10 mm 50 m 14.146.40 Tripolar Blue / Yellow-Green / Black 4 mm² 12.7 mm 50 m
Technical Specifications
Brand Osculati Conductor Material Copper Cable Type Tripolar Insulation Material Extra-Insulating PVC Outer Sheath Color Medium Grey Standard IEC 60332-3-22 Compliance CEI 20-22 II, CEI 20-371, EU Directive 2011/95/CE Properties Flame Retardant, Oil Resistant Roll Length 50 m
Sold individually in the selected conductor configuration and cross-section.
-
