Viadana Wind Speed Fiddle Ball Bearing Blocks with Becket for 8-12 mm Rope

ID 1391256

$ 49.63

1-2 weeks delivery time

Diameter, mm:

Viadana Fiddle Ball Bearing Blocks with Becket are compact two-sheave sailing blocks designed for multi-part rope systems. The ball-bearing construction supports smooth rope movement, while the integrated becket provides an additional attachment point for the standing end of the line. The range is available for 8, 10 and 12 mm ropes and includes Viadana articles 89.57, 90.57 and 91.54.

Description
Ask a Question

Viadana Wind Speed Ball Bearing Fiddle Blocks with Becket for Rope up to 8-12 mm - Viadana 89.57 / 90.57 / 91.54

Viadana Wind Speed Ball Bearing Fiddle Blocks with Becket are designed for sailing and marine rigging systems that require a compact two-sheave arrangement together with an additional becket attachment point. The fiddle-block configuration allows several rope passes to be incorporated into a relatively compact assembly, making it suitable for multi-part control and purchase systems.

Each block is fitted with two sheaves running on ball bearings, helping reduce friction and provide smooth rope movement during trimming and repeated adjustment. The integrated becket provides an additional attachment point for the standing end of the line, allowing the block to be used in more complex rigging arrangements.

The range includes versions for 8, 10 and 12 mm ropes. Working load increases from 150 kg on the 8 mm model to 280 kg on the 12 mm version, while breaking load ranges from 750 to 1000 kg. This allows the appropriate block to be selected according to rope size and required load capacity.

The three variants are identified as Viadana articles 89.57, 90.57 and 91.54, corresponding to FNI product numbers 7878033, 7878034 and 7878035 respectively.

Product Features
- Brand: Viadana
- Series: Wind Speed
- Product type: Ball bearing fiddle block with becket
- Configuration: Two sheaves with becket
- Bearing type: Ball bearings
- Available rope sizes: 8, 10 and 12 mm
- Working load range: 150-280 kg
- Breaking load range: 750-1000 kg
- Application: Sailing and marine multi-part rigging systems
Available Variants

Rope Size Sheaves Working Load Breaking Load Viadana Article FNI Product Number

8 mm 2 150 kg 750 kg 89.57 7878033

10 mm 2 230 kg 950 kg 90.57 7878034

12 mm 2 280 kg 1000 kg 91.54 7878035

Rope Size	Sheaves	Working Load	Breaking Load	Viadana Article	FNI Product Number
8 mm	2	150 kg	750 kg	89.57	7878033
10 mm	2	230 kg	950 kg	90.57	7878034
12 mm	2	280 kg	1000 kg	91.54	7878035
