Viadana Wind Speed Ball Bearing Double Fiddle Block with Swivel Head for Rope up to 8-12 mm

ID 1391252

$ 45.73

1-2 weeks delivery time

Diameter, mm:

Viadana Wind Speed Ball Bearing Double Fiddle Blocks with Swivel Head are designed for multi-part sailing and rigging systems where smooth rope handling and compact load distribution are required. The blocks feature reinforced black nylon construction with stainless steel components, two ball-bearing sheaves and a swivel head. Available for ropes up to 8, 10 and 12 mm with 34, 45 and 56 mm sheaves, the range provides breaking loads from 800 to 1450 kg and working loads from 300 to 580 kg. Corresponding Viadana articles are 89.56, 90.56 and 91.53.

Description
Ask a Question

Viadana Wind Speed Ball Bearing Double Fiddle Blocks with Swivel Head for Rope up to 8-12 mm, 34-56 mm Sheaves - Osculati 55.079.08 / 55.079.10 / 55.079.12

Viadana Wind Speed Ball Bearing Double Fiddle Blocks with Swivel Head are designed for sailing and marine rigging systems that require a two-sheave fiddle block configuration for multi-part rope arrangements. The fiddle layout provides a compact way to route several rope passes through the block, while the swivel head allows the block to align with the direction of the applied load.

The blocks belong to the Wind Speed ball-bearing range and combine reinforced black nylon construction with stainless steel components. Both sheaves operate on ball bearings to provide smooth rope travel and efficient movement during repeated trimming and adjustment. The range is available in three sizes for ropes up to 8, 10 and 12 mm.

The 8 mm version uses 34 mm sheaves, the 10 mm version uses 45 mm sheaves and the 12 mm version uses 56 mm sheaves. Breaking loads range from 800 to 1450 kg, with working loads from 300 to 580 kg. The corresponding Viadana articles are 89.56, 90.56 and 91.53, matched with Osculati codes 55.079.08, 55.079.10 and 55.079.12 respectively.

Product Features

Brand: Viadana
Series: Wind Speed
Product type: Double fiddle block
Head type: Swivel head
Configuration: Two sheaves
Body: Reinforced black nylon
Metal components: Stainless steel
Bearing type: Ball bearings
Available rope capacities: Up to 8, 10 or 12 mm
Available sheave diameters: 34, 45 or 56 mm
Breaking load range: 800-1450 kg
Working load range: 300-580 kg

Available Variants

Max. Rope Diameter	Sheave Diameter	Breaking Load	Working Load	Viadana Article	Osculati Code	FNI Product Number
8 mm	34 mm	800 kg	300 kg	89.56	55.079.08	7878030
10 mm	45 mm	950 kg	370 kg	90.56	55.079.10	7878031
12 mm	56 mm	1450 kg	580 kg	91.53	55.079.12	7878032
