Wichard Forged Self-Locking Bow Shackles are manufactured from forged marine-grade 316L stainless steel and are designed for professional sailing, rigging, mooring, and lifting applications. The self-locking pin prevents accidental loosening under vibration, while the wide bow profile allows multi-directional loading. Available in diameters from Ø4 mm to Ø16 mm with breaking loads up to 8,800 kg.
- Description
- Ask a Question
-
Wichard Forged Self-Locking Bow Shackles Stainless Steel 316L
Wichard Forged Self-Locking Bow Shackles are premium-quality marine shackles manufactured from forged 316L stainless steel for maximum strength, corrosion resistance, and long service life. Their self-locking pin system helps prevent accidental unscrewing caused by vibration, making them ideal for critical rigging and marine hardware applications.
Supplied through Plastimo, these original Wichard shackles feature a wide bow profile that accommodates multiple attachment points and allows greater articulation than straight shackles. They are suitable for sailing yachts, offshore vessels, deck hardware, mooring systems, lifting equipment, and professional marine installations.
Features
- Original Wichard products
- Official Plastimo distributor references included
- Original Wichard OEM part numbers included
- Forged marine-grade 316L stainless steel
- Self-locking pin design
- Wide bow profile for multi-directional loading
- Excellent corrosion resistance
- Designed for demanding marine and offshore environments
Available Variations
Plastimo SKU Wichard OEM Diameter Length Width Breaking Load SWL 100716 W 1241 Ø 4 mm 18 mm 8 mm 560 kg 112 kg 100718 W 1243 Ø 6 mm 28 mm 12 mm 1,200 kg 240 kg 100719 W 1244 Ø 8 mm 37 mm 16 mm 2,160 kg 432 kg 100720 W 1245 Ø 10 mm 47 mm 20 mm 3,440 kg 688 kg 409471 W 1246 Ø 12 mm 55 mm 24 mm 4,800 kg 960 kg 415076 W 1247 Ø 16 mm 70 mm 32 mm 8,800 kg 1,760 kg
Technical Specifications
Brand Wichard Distributor Plastimo Material Forged stainless steel 316L Type Self-Locking Bow Shackle Diameter Range 4–16 mm Safe Working Load (SWL) 112–1,760 kg Breaking Load 560–8,800 kg Pin Type Self-locking Applications Sailing rigging, standing rigging, deck hardware, lifting systems, mooring equipment and professional marine installations
Applications
- Sailing and yacht rigging
- Standing rigging connections
- Deck hardware
- Mooring systems
- Marine lifting applications
- Offshore installations
- Professional marine equipment
-
