Tecnoseal Suzuki 200-250HP Outboard Anode Kit

Name: Tecnoseal Suzuki 200-250HP Outboard Anode Kit
SKU: Tecnoseal KITSUZUKI200-250 / Osculati-43.372.00

SKU: Tecnoseal KITSUZUKI200-250 / Osculati-43.372.00

ID 1406316

$ 93.36

1-2 weeks delivery time

Type:

Zinc
Magnesium
Aluminium

Item:

780 g
230 g
380 g

The Tecnoseal KITSUZUKI200-250 series includes four-piece sacrificial anode kits designed for Suzuki 200-250HP outboard engines. Each kit contains one stern bracket anode (01214 series) and three small block anodes (01204 series), helping protect compatible metallic outboard components against galvanic corrosion. Available in zinc (KITSUZUKI200-250, 0.78 kg), aluminium (KITSUZUKI200-250AL, 0.38 kg) and magnesium (KITSUZUKI200-250MG, 0.23 kg), all three versions feature the same component arrangement with material-specific part numbers. Installation hardware is not included.

Description
Ask a Question

Tecnoseal KITSUZUKI200-250 Suzuki 200–250HP Outboard Anode Kit – Zinc, Aluminium & Magnesium

The Tecnoseal KITSUZUKI200-250 series includes four-piece sacrificial anode kits designed for Suzuki 200–250HP outboard engines. Each kit contains one stern bracket anode and three small block anodes to help protect compatible metallic outboard components against galvanic corrosion.

The kits are available in zinc, aluminium and magnesium, with corresponding complete-kit cross-references Osculati 43.372.00, 43.372.01 and 43.372.02. All three material variants contain the same number and types of components, with material-specific part numbers and different weights. Installation hardware is not included.

Technical Specifications

Manufacturer	Tecnoseal
Product Type	Outboard Engine Anode Kit
Engine Manufacturer	Suzuki
Compatible Engine Range	200–250HP
Available Materials	Zinc, Aluminium, Magnesium
Number of Anodes	4 pieces per kit
Kit Components	1 stern bracket anode, 3 small block anodes
Installation Hardware	Not included

Available Variants and Osculati Cross-References

Tecnoseal Code	Material	Kit Weight	Osculati Reference
KITSUZUKI200-250	Zinc	0.78 kg (1.72 lbs)	43.372.00
KITSUZUKI200-250AL	Aluminium	0.38 kg (0.84 lbs)	43.372.01
KITSUZUKI200-250MG	Magnesium	0.23 kg (0.51 lbs)	43.372.02

Kit Contents

Component	Quantity	Zinc Kit	Aluminium Kit	Magnesium Kit
Stern Bracket Anode	1	01214	01214AL	01214MG
Small Block Anode	3	01204	01204AL	01204MG

Compatibility and Complete Kit References

Compatible Engine Manufacturer: Suzuki
Compatible Power Range: 200–250HP
Zinc Kit: Tecnoseal KITSUZUKI200-250 – Osculati 43.372.00
Aluminium Kit: Tecnoseal KITSUZUKI200-250AL – Osculati 43.372.01
Magnesium Kit: Tecnoseal KITSUZUKI200-250MG – Osculati 43.372.02

Individual Component OEM and Cross-References

Stern Bracket Anode – Tecnoseal 01214 Series

Suzuki OEM: 55321-94900, 55320-94900
Additional Tecnoseal references: 00840, 00926, 01254

Small Block Anode – Tecnoseal 01204 Series

Suzuki OEM: 55320-95310, 55320-95311, 55321-93J00
Additional Tecnoseal reference: 00930
Osculati 43.903.20 – Zinc
Osculati 43.903.21 – Aluminium
Osculati 43.903.22 – Magnesium

Reference distinction: Osculati 43.372.00, 43.372.01 and 43.372.02 identify the complete four-piece anode kits. Osculati 43.903.20, 43.903.21 and 43.903.22 refer to individual small block anodes, not the complete kits. The listed Suzuki OEM references also apply to individual components.

Sacrificial Corrosion Protection

The four anodes in each kit are intended to provide sacrificial corrosion protection for compatible metallic components of Suzuki outboard engines. The sacrificial material corrodes preferentially when correctly installed and electrically connected to the protected components.

The appropriate material should be selected according to the engine manufacturer's recommendations and the vessel's operating water conditions.

Installation and Replacement

Before installation, verify the engine model and confirm that the replacement anodes correspond to the existing mounting locations. Inspect the anodes periodically and replace them when the sacrificial material becomes significantly depleted or damaged.

Installation hardware is not included. Reuse existing hardware only when it is suitable and in serviceable condition, or obtain the appropriate replacement fasteners separately.

Scope of Supply

1 × Stern Bracket Anode – selected material
3 × Small Block Anodes – selected material

Total: 4 sacrificial anodes per kit. Installation hardware is not included.
