Tecnoseal Galvion Elements Zinc Pencil Anodes with Galvanised Steel Core – M6 Thread

Name: Tecnoseal Galvion Elements Zinc Pencil Anodes with Galvanised Steel Core – M6 Thread
SKU: Tecnoseal 20007

ID 1406115

$ 29.62

1-2 weeks delivery time

Size:

26.7x19
38x19

Item:

150 g
70 g

Tecnoseal Galvion Elements zinc pencil anodes feature cylindrical sacrificial zinc bodies with galvanised steel cores and internal M6 threaded inserts for marine corrosion protection applications. The range includes model 20007 with a 26.7 mm diameter, 19 mm body length and 0.07 kg weight, and model 20003-1 with a larger 38 mm diameter, the same 19 mm body length and 0.15 kg weight. Both versions have recessed steel inserts rather than protruding threaded studs. They correspond to original part references G1050M2 and G1500(M), respectively, and are supplied individually.

Description
Ask a Question

Tecnoseal Galvion Elements Zinc Pencil Anodes with Galvanised Steel Core – M6 Thread

Tecnoseal Galvion Elements zinc pencil anodes are sacrificial corrosion protection components featuring cylindrical zinc bodies with integrated galvanised steel cores. The steel inserts provide internal threaded mounting connections, allowing the anodes to be secured to compatible marine equipment while the surrounding zinc acts as the sacrificial material.

This range includes two models, Tecnoseal 20007 and 20003-1. Both have a body length of 19 mm (0.75 in) and an internal M6 threaded insert. Unlike versions fitted with protruding threaded studs, these models use a recessed mounting arrangement within the cylindrical zinc body.

The Tecnoseal 20007 measures 26.7 mm (1.05 in) in diameter and weighs 0.07 kg (70 g). The larger Tecnoseal 20003-1 has a 38 mm (1.50 in) diameter and weighs 0.15 kg (150 g). Both are supplied individually with integrated galvanised steel inserts.

Key Features

Manufacturer: Tecnoseal
Product Series: Galvion Elements
Product Type: Sacrificial pencil anode with insert
Anode Material: Zinc
Core Material: Galvanised steel
Available Models: 20007 and 20003-1
Body Diameters: 26.7 mm and 38 mm
Body Length: 19 mm
Mounting Thread: M6
Mounting Configuration: Recessed threaded steel insert
Individual Weights: 0.07 kg and 0.15 kg
Supply: Individual zinc anode with integrated steel core

Available Models and Technical Specifications

Tecnoseal Code	Diameter (Ø)	Body Length (l)	Thread (m)	Weight	Original Part Number
20007	26.7 mm / 1.05 in	19 mm / 0.75 in	M6	0.07 kg / 70 g	G1050M2
20003-1	38 mm / 1.50 in	19 mm / 0.75 in	M6	0.15 kg / 150 g	G1500(M)

Tecnoseal 20007 – Galvion Elements Zinc Anode Ø26.7 x 19 mm

The Tecnoseal 20007 features a cylindrical zinc body measuring 26.7 mm (1.05 in) in diameter and 19 mm (0.75 in) in length. A galvanised steel core with an internal M6 thread is incorporated into the anode body, providing a recessed mounting connection.

It weighs 0.07 kg (0.15 lbs) and corresponds to original part number G1050M2. Its compact cylindrical design allows installation in compatible mounting arrangements requiring this diameter and thread size.

Product Code: 20007
Original Part Number: G1050M2
Diameter (Ø): 26.7 mm / 1.05 in
Body Length (l): 19 mm / 0.75 in
Internal Thread (m): M6
Core: Galvanised steel
Weight: 0.07 kg / 0.15 lbs
EAN: 8058774839243

Tecnoseal 20003-1 – Galvion Elements Zinc Anode Ø38 x 19 mm

The Tecnoseal 20003-1 is the larger diameter version of this Galvion Elements anode configuration. Its zinc body measures 38 mm (1.50 in) in diameter and 19 mm (0.75 in) in length, with an integrated galvanised steel core featuring an internal M6 thread.

The anode weighs 0.15 kg (0.33 lbs) and corresponds to original part number G1500(M). Compared with the 20007, it provides a wider zinc body while retaining the same body length and M6 mounting connection.

Product Code: 20003-1
Original Part Number: G1500(M)
Diameter (Ø): 38 mm / 1.50 in
Body Length (l): 19 mm / 0.75 in
Internal Thread (m): M6
Core: Galvanised steel
Weight: 0.15 kg / 0.33 lbs
EAN: 8058774839250

Galvanised Steel Core and Mounting Configuration

Both anodes feature an integrated galvanised steel core with an M6 threaded mounting connection. The internal thread is recessed within the cylindrical zinc body, rather than extending outward as an external threaded stud.

The zinc forms the sacrificial portion of the component, while the steel core provides the mechanical mounting interface. This configuration differs from the Galvion Elements models with protruding threaded extensions.

Original Part Number Cross-References

Tecnoseal Code	Original Part Number
20007	G1050M2
20003-1	G1500(M)

Model Selection

Select the appropriate Tecnoseal Galvion Elements pencil anode according to the original part number, body diameter and mounting configuration.

The 20007 features a 26.7 mm diameter and weighs 70 g, while the 20003-1 measures 38 mm in diameter and weighs 150 g. Both models have a 19 mm body length and internal M6 threaded insert.

Before ordering, verify the existing mounting arrangement and available clearance. Models with recessed internal threads should not be confused with anodes featuring external threaded steel studs.

Supply: One zinc sacrificial anode with integrated galvanised steel core.
