Tecnoseal 66M-45371-00 Yamaha 9.9–15 HP Outboard Trim Tab Anode

Name: Tecnoseal 66M-45371-00 Yamaha 9.9–15 HP Outboard Trim Tab Anode
SKU: Tecnoseal 01136

ID 1405527

$ 47.58

1-2 weeks delivery time

Type:

Zinc
Magnesium

Item:

20 g
90 g

The Tecnoseal 01136 series consists of sacrificial trim tab anodes designed for Yamaha 9.9–15 HP outboard motors, corresponding to Yamaha OEM part number 66M-45371-00. Each anode features a tall, angled vertical fin attached to a compact mounting base with two fastening holes, helping protect submerged metallic outboard components against galvanic corrosion. The anode measures 53 mm in length (l), 38 mm in width (a) and 62 mm in overall height (h), with 7 mm mounting-hole diameter (Ø). Two material versions are available: zinc (Tecnoseal 01136, 90 g) and magnesium (Tecnoseal 01136MG, 20 g). Both versions share identical dimensions and mounting geometry, allowing selection of the appropriate sacrificial material according to operating water conditions.

Description
Ask a Question

Tecnoseal 66M-45371-00 Yamaha 9.9–15 HP Outboard Trim Tab Anode

The Tecnoseal 01136 series consists of sacrificial trim tab anodes designed for Yamaha 9.9–15 HP outboard motors. Corresponding to Yamaha OEM part number 66M-45371-00, these replacement anodes help protect submerged metallic components of compatible Yamaha outboard lower units against galvanic corrosion.

Each anode features a tall, angled vertical fin rising from a compact mounting base. Unlike conventional round trim tab anodes, this model has a distinctive fin profile and a base with two fastening holes. The sacrificial metal body provides corrosion protection for surrounding metallic components by gradually corroding during service.

The anode measures 53 mm (2.09 in) in length (l), 38 mm (1.50 in) in width (a) and 62 mm (2.44 in) in overall height (h). The mounting-hole diameter (Ø) is 7 mm (0.28 in). These dimensions correspond to the technical drawing in the Tecnoseal catalogue and are identical for both available material versions.

Two material versions are available. The zinc version, Tecnoseal 01136, weighs 0.09 kg (0.20 lbs), while the magnesium version, Tecnoseal 01136MG, weighs 0.02 kg (0.04 lbs). Both versions share the same shape, dimensions and mounting configuration, allowing the appropriate sacrificial anode material to be selected according to the vessel's operating water conditions.

The Tecnoseal 01136 series is intended for Yamaha 9.9–15 HP outboard applications. Before replacing the existing trim tab, the OEM reference, mounting-hole arrangement and vertical fin profile should be compared with the original component.

Technical Specifications

Manufacturer	Tecnoseal
Product Type	Outboard Trim Tab Anode
Compatible Manufacturer	Yamaha
Compatible Outboards	9.9–15 HP
Yamaha OEM Reference	66M-45371-00
Available Materials	Zinc, Magnesium
Construction	Angled vertical fin with compact mounting base
Mounting Configuration	Two fastening holes

Available Versions

Tecnoseal Code	Material	Weight	EAN
01136	Zinc	0.09 kg (0.20 lbs)	8033837065418
01136MG	Magnesium	0.02 kg (0.04 lbs)	8052744983677

Dimensions and Mounting Specifications

Length (l)	53 mm (2.09 in)
Width (a)	38 mm (1.50 in)
Overall Height (h)	62 mm (2.44 in)
Mounting-Hole Diameter (Ø)	7 mm (0.28 in)

Compatibility and OEM References

Compatible Manufacturer: Yamaha
Outboard Power Range: 9.9–15 HP
Application: Outboard trim tab anode
Yamaha OEM Part Number: 66M-45371-00
Zinc Version: Tecnoseal 01136
Magnesium Version: Tecnoseal 01136MG

Key Features

Designed for compatible Yamaha 9.9–15 HP outboard motors.
Corresponds to Yamaha OEM part number 66M-45371-00.
Distinctive tall, angled vertical trim tab fin.
Compact mounting base with two fastening holes.
Helps protect submerged metallic lower-unit components against galvanic corrosion.
Available in zinc and magnesium versions.
Overall length: 53 mm.
Width: 38 mm.
Overall height: 62 mm.
Mounting-hole diameter: 7 mm.
Identical dimensions and mounting geometry for both material versions.

Compatibility Note: Before ordering, verify the Yamaha outboard model, OEM part number and existing trim tab dimensions. Compare the fin profile, mounting base and fastening-hole arrangement with the original component. Select the appropriate sacrificial anode material according to the vessel's operating water conditions.
