ID
1264969
$ 72.58
1-2 weeks delivery time
-
+
The Johnson Pump 09-812B-1 flexible impeller kit uses MC97 material for cooling-focused water-pumping duties such as engine cooling, water transfer, washdown, and bilge pumping. Built for Johnson F6-series applications, it features a spline-drive hub and specified dimensions of 57.1 mm diameter and 48.2 mm depth, and it is listed as a replacement option for multiple OEM impellers including Jabsco and Volvo Penta references. This item is noted as no longer available, with Johnson Pump 09-812BT-1 listed as an alternative.
- Description
- Ask a Question
-
Johnson 09-812B-1 MC97 Flexible Impeller Service Kit
The Johnson Pump 09-812B-1 is a genuine MC97 flexible impeller kit intended for a wide range of water-pumping tasks, including engine cooling, water transfer, washdown, and bilge pumping. It is engineered for Johnson Pump F6-series applications and is specified for use with F6B-9 and F6B-902 pump models.
Application
- Engine cooling
- Water transfer
- Washdown
- Bilge pumping
Compatibility
- Johnson Pump F6B-9 pumps
- Johnson Pump F6B-902 pumps
- Indmar pump models 68-5001
- Indmar pump models 68-5020
- Marine Power 0562-000 models
- Toyota 16860-67010 pump models
- Volvo Penta pumps 3812518
- Volvo Penta pumps 3812519
- Volvo Penta pumps 3812520
- Volvo Penta pumps 3812522
- Yamaha 10-24633 pump models
- Yamaha B02 P726 pump models
- Yanmar 119773-42500
- Yanmar 119773-42650
Johnson Pump F6B-9 and F6B-902 Pump Model References
- 10-13208-01
- 10-13208-02
- 10-13331-01
- 10-13333-01
- 10-13345-01
- 10-13356-01
- 10-13356-03
- 10-13356-04
- 10-13357-01
- 10-13376-01
- 10-13432-01
- 10-24232 series (1 through 8B)
- 10-24234 series (1 and 2)
- 10-24302 series (01 and 02)
- 10-24316 series (01 and 02)
- 10-24412 series (01 and 02)
- 10-24432 series (01 and 02)
- 10-24493 series (01 and 02)
- 10-24515-01
- 10-24562 series (01 and 02)
- 10-24563-01
- 10-24568-01
- 10-24591-01
- 10-24592-01
- 10-24593-01
- 10-24633-01
Technical Specifications
Brand Johnson Pump Part Number 09-812B-1 Article Number 6609812B-1 EAN 8719182044925 Pump Series F6 Reference 11 Material MC97 (for cooling) Diameter 57.1 mm (also listed as 57 mm) / 2.25 in Depth 48.2 mm (also listed as 48.4 mm) / 1.9 in Impeller Hub Spline Drive Shaft Dimension Splines Shaft Diameter 16 mm Number of Blades 12 Insert Material Brass Shipping Weight 0.40 kg
Product Details
- Portfolio: Impeller
- Impeller type: Flexible impeller (MC97)
- Intended pump models: F6B-9 and F6B-902
Replacement References
- Johnson Pump 09-812B-1
- Jabsco 13554-0001 (also listed as USA)
- Toyota 16847-67010
- Volvo Penta 3584350
- Yamaha 6TA-12457-00
- Yanmar 119773-42600
- Replaces: 13554-0001
Availability
No Longer Available. Alternative listed: Johnson Pump 09-812BT-1.
-
