The VDO 350-040-020C Cockpit International oil pressure gauge is a 52 mm, 24V instrument designed for accurate engine oil pressure monitoring up to 80 PSI, helping you keep engine lubrication under control in demanding operating conditions. Built for VDO engine monitoring setups, it works with a 10–184 Ohm VDO pressure sender signal and uses robust AMP blade connectors for dependable wiring, while the black cockpit-style dial integrates cleanly into professional dashboards and instrument panels.
- Description
- Ask a Question
-
Cockpit International 52 mm Oil Pressure Gauge for 24V Systems
The VDO 350-040-020C is a Cockpit International engine oil pressure gauge designed for clear, stable oil-pressure readings in 24V electrical systems. As part of a VDO engine monitoring instrument setup, it displays oil pressure up to 80 PSI (0–5 bar) and is intended to be used with a VDO pressure sender signal of 10–184 Ohm, helping drivers and technicians quickly verify lubrication performance and spot pressure changes early.
Compatibility
- 24V vehicle electrical systems
- VDO engine monitoring installations using a 10–184 Ohm VDO pressure sender signal
Technical Specifications
Part Number 350-040-020C Series Cockpit International Function Engine oil pressure Pressure Range 0–5 bar (up to 80 PSI) Signal 10–184 Ohm Operating Voltage 21.5–30 V DC (24V system) Current Consumption (Without Illumination) 82 mA Reverse Polarity Protection Yes Installation Hole Diameter 52 mm (2 1/16 inch) Outside Diameter 59.25 mm (2 1/3 inch) Installation Depth 67.5 mm Locking Height With Bracket 0.5–8 mm Main Connection AMP male blade connector 6.3 x 0.8 mm (3x) Illumination Connection AMP male blade connector 6.3 x 0.8 mm (2x) Deflection Angle 90° Dial Color Black Pointer Red backlight Dial Illumination Floodlight 24V, 2W, white, green, red Warning Indication None Lens Single anti-glare Bezel Triangular black (threaded ring) Front Protection Class IP64 (DIN 40050) Rear Protection Class IP42 (DIN 40050) Operating Temperature -30°C to +85°C CE Yes Mechanical Shock (8 Hours) Max 1G, 25 Hz to 2000 Hz EMC According to EN 13309 and ISO 13766 Housing Plastic, flame retardant Country of Origin Malaysia EAN Code 4103590690692 HS Code 85122000 Weight 1.00 kg Packaging OEM bulk (10 pieces) Bezel Interchangeable Yes (special tool required)
Product Details
- Brand: VDO
- Component Type: Engine oil pressure gauge
- Instrument Family: Cockpit International
- Typical Location: Dashboard and cockpit instrument panel
- Pack Content: 10 pieces pressure gauges; steel bracket (zinc-plated and chromated)
Features
- Clear 52 mm gauge format for fast oil-pressure checks at a glance
- Designed for stable readings across 24V operating conditions
- Compatible with VDO 10–184 Ohm pressure sender signal for straightforward integration
- Durable Cockpit International design with IP-rated protection for dependable panel mounting
-
