The VDO 340-808-001-004G generator-type tacho and speed sender is an RPM generator designed to drive speedometer and tachometer instrumentation from a mechanical drive. Built with a 7/8"-18 NS-2A female thread and a 2-pole insulated return signal, it delivers 19.3 V at 2,000 RPM and supports operation up to 3,000 RPM, with dual M4 threaded electrical connections for a secure, service-friendly installation.
- Description
- Ask a Question
-
VDO Generator-Type Tacho and Speed Sender, 7/8-18 Thread
Designed for generator-driven instrumentation, the VDO 340-808-001-004G is an RPM generator sender used to supply a speedometer and tachometer signal from a mechanical drive point. With its 7/8"-18 NS-2A female mounting thread and 2-pole insulated return signal, it provides stable output for dependable RPM and speed indication.
Compatibility
- Generator Speedometer Systems
- Generator Tachometer Systems
Technical Specifications
Part Number 340-808-001-004G Sender Type Generator, 3,000 RPM Maximum Number of Revolutions 3,000 RPM Thread 7/8" - 18 NS-2A Female Signal 2-pole insulated return Connector 2-pole M4 thread No Load Voltage 19.3 V at 2,000 RPM Voltage Tolerance ± 1% at nominal value at +20°C Operating Temperature -25°C to +90°C Overall Length Without Thread 80 mm Maximum Driving Torque 500 pcm Protection Rating IP54 (DIN 40050) EAN 4103590949493 Weight 0.40 kg
Product Details
- Brand: VDO
- Component Type: Generator tacho and speed sender (RPM generator sender)
- Functionality: Generator-type sender for tachometer and speedometer instrumentation
- Signal Return: Insulated return
- Packaging: VDO sensor retail package
Features
- Generator-style output suited to classic and industrial tacho/speed systems
- 2-pole insulated return signal supports stable, consistent instrument readings
- 7/8"-18 NS-2A female thread provides secure mechanical mounting
- M4 threaded electrical connections help create a robust, serviceable installation
- IP54-rated protection for dependable operation in demanding environments
Retail Package Contents
- VDO 340-808-001-004G generator tacho and speed sender
- VDO sensors are, unless otherwise noted, delivered without connection hardware
-
