The VDO Cockpit International 333-035-002G analog tachometer provides clear, dependable engine speed monitoring from 0 to 4,000 RPM for 12V automotive, marine, and industrial instrument panels. Built for confident operation in harsh environments, it features IP64 front protection, a black dial with a red backlit pointer, and optional multi-color dial illumination to keep RPM data readable day or night, while AMP male blade connectors support secure electrical integration with common engine monitoring setups.
- Description
- Ask a Question
-
Cockpit International 80 mm Analog Tachometer 0–4,000 RPM
Designed for accurate RPM feedback in demanding installations, the VDO 333-035-002G Cockpit International tachometer is an analog engine-speed instrument for 12V DC systems. With a clear 0 to 4,000 RPM scale, a triangular black bezel, and a red backlit pointer, it supports confident engine operation in automotive, marine, and industrial dashboards where quick readability matters.
Compatibility
- Automotive 12V DC electrical systems (11–16V DC)
- Marine 12V DC electrical systems (11–16V DC)
- Industrial 12V DC electrical systems (11–16V DC)
- VDO engine monitoring system installations
Technical Specifications
Part Number 333-035-002G Series Cockpit International Measurement Range 0 to 4,000 RPM Operating Voltage 11–16V DC (12V nominal) Current Consumption (Without Illumination) < 100 mA Panel Hole Diameter 80 mm (3 1/8 inch) Outside Diameter 85 mm (3 1/3 inch) Installation Depth 91 mm Connector 8-pole AMP male blade connector, 6.3 x 0.8 mm Illumination Connection AMP male blade connector, 6.3 x 0.8 mm (4x) Signal Input Alternator terminal W; ignition terminal 1 Dial Color Black Pointer Red backlight Dial Illumination Optional Floodlight Double: 12V, 3.4 W (white, green, red); 24V, 3 W (optional) Lens Plastic, single, non-reflective, anti-glare Bezel Interchangeable black triangle bezel (special tool required) Front Protection Rating IP64 (DIN 40050), ozone proof, UV proof Rear Protection Rating IP42 (DIN 40050) Operating Temperature -20°C to +70°C Mechanical Shock (8 Hours) Max 1G, 25 Hz to 2000 Hz EMC Test According to EN 13309 and ISO 13766 Reverse Polarity Protection Yes Warning Indication None Programming Yes CE Yes Country of Origin Switzerland EAN 4103590659583 HS Code 90292031 Weight 0.38 kg Successor A2C3832990001
Product Details
- Brand: VDO
- Component Type: Analog tachometer (engine RPM gauge)
- Typical Location: Dashboard and cockpit instrument panels
- Mounting Style: Triangular black bezel with threaded ring; locking height with bracket 0.5–12 mm; locking height with Spinlock nut optional 0.5–23 mm
- Retail Package: 1 tachometer
Features
- Accurate, easy-to-read 0–4,000 RPM analog display for confident engine operation
- IP64 front protection helps the instrument stay reliable in dust and spray-prone environments
- Enhanced night visibility with a red backlit pointer and optional multi-color dial illumination
- Secure electrical integration via AMP male blade connectors
- Supports common tachometer signal sources via alternator terminal W or ignition terminal 1
Box Contents
- VDO Cockpit International 333-035-002G tachometer
- 2 steel brackets, zinc-plated and chromatized
-
