Simrad HALO24 Radar

ID 1347236

$ 5,029.32

1-2 weeks delivery time

- +

Add to cart

The Simrad HALO24 Radar is a 24-inch dome radar with up to 48 nm range, advanced pulse compression, Dual Range operation, 60 RPM rotation, and VelocityTrack™ Doppler technology. It provides high-quality short, mid, and long-range detection with automatic target monitoring. Brand: Simrad, article 000-14535-001, barcode 9420024173770.

Description
Ask a Question

Simrad HALO24 Radar

The Simrad HALO24 Radar is a compact 24-inch dome radar offering up to 48 nautical miles range. Designed for smaller powerboats, it delivers high-quality short, mid and long-range detection with advanced pulse compression technology and beam sharpening for clear target separation.

With industry-first 60 RPM rotation at ranges up to 1.5 nm, HALO24 provides near real-time updates for superior collision avoidance. VelocityTrack™ Doppler technology highlights approaching and receding targets with colour coding, improving situational awareness. Dual Range mode allows simultaneous monitoring of near and far targets.

Key Features

48 nm range with compact 24-inch dome
Advanced pulse compression with beam sharpening
Simultaneous Dual Range operation
60 RPM rotation up to 1.5 nm
VelocityTrack™ Doppler technology
Harbour, offshore, weather and bird modes
MARPA target tracking (10 targets, 20 in dual range)
Instant wake from standby
Automatic target monitoring with no manual selection required

Technical Data

Article	000-14535-001
Series	HALO
Range	Up to 48 nm
Rotation Speed	Up to 60 RPM (≤1.5 nm)
Ethernet	100 Base-T
Protection Class	IPX6
Voltage	12 / 24 VDC
Product Height	610 mm
Interface	Simrad MFD
Certification	FCC; Part 47 CFR 80 and 90; RED; Article 3 of Directive 99/5/EC; CE; EN; EN302-248 V2.1.1; Industry Canada; RSS238; RCM (C-Tick); IEC60945 Sec 9.2, 9.3; 10.3-10.9; 11.2; IEC60950 Electrical Safety
Sales Unit	1 Piece

Brand: Simrad (Article Code: 000-14535-001) (Barcode: 9420024173770)
