Lowrance 000-15997-001 - Fishfinder HDS PRO 9 No Transducer

Lowrance 000-15997-001 - Fishfinder HDS PRO 9 No Transducer

The Lowrance HDS PRO 9 fishfinder delivers advanced sonar performance, ultra-high-definition imaging, and extensive system integration for professional-level fishing and navigation. Designed as the next evolution of the HDS series, this unit allows anglers to detect more structure and fish with enhanced precision using Active Imaging™ HD and optional ActiveTarget® live sonar modules.

Advanced Sonar Technology

The integrated next-generation sonar system features dual independent 9 Pin Xsonic transducer ports with up to 1 kW power output per channel. Active Imaging™ HD provides highly detailed Lowrance CHIRP sonar, SideScan, and DownScan Imaging™ views for accurate underwater tracking.

FishReveal™ technology is available on both SideScan and DownScan modes, helping identify fish around and beneath the vessel more efficiently. Support for FishReveal™ on SideScan and DownScan requires the optional S3100 module.

High-Visibility SolarMAX™ HD Display

The 9-inch SolarMAX™ HD touchscreen delivers clear and vibrant visuals with a 1280 x 720 resolution. The display remains easy to read from wide viewing angles, in direct sunlight, and while wearing polarised glasses. Detailed chart rendering supports C-MAP Discover, Reveal, and Navionics+ / Platinum charts for improved navigation and fishing accuracy.

Expanded Connectivity And Integration

The HDS PRO 9 is designed for complete boat customisation and seamless integration with modern marine electronics. Compatible systems include Halo radar, NAC1 and NAC2 autopilot systems, NMEA 2000®, USB connectivity, and SiriusXM® Weather/Audio.

The unit also supports ActiveTarget® 2 Live Sonar for real-time fish and structure tracking with improved resolution. Plug-and-play support for dual ActiveTarget® systems enables multiple simultaneous sonar views, including expanded Front and Scout modes for advanced bait tracking.

Technical Data

Brand: Lowrance
