Lowrance HDS PRO 12 (000-16003-001) includes a 12-inch SolarMAX HD display with 1280 x 800 resolution, dual 9-pin XSONIC sonar ports, 1 kW per channel output, and compatibility with Active Imaging HD and ActiveTarget live sonar.
- Description
- Ask a Question
-
Lowrance 000-16003-001 - Fishfinder HDS PRO 12 No Transducer
The Lowrance HDS PRO 12 fishfinder delivers advanced sonar capabilities, ultra-high-definition imaging, and complete marine system integration for serious anglers and professional navigation. As the latest development in the HDS series, it offers enhanced underwater detail and improved fish tracking with support for Active Imaging™ HD and optional ActiveTarget® live sonar technology.
High-Performance Sonar System
The built-in next-generation sonar system features dual independent 9 Pin Xsonic transducer ports with up to 1 kW output per channel. Active Imaging™ HD provides highly detailed Lowrance CHIRP sonar, SideScan, and DownScan Imaging™ views for accurate underwater structure and fish identification.
FishReveal™ functionality is available on both SideScan and DownScan modes, making it easier to detect fish around and beneath the vessel. Support for FishReveal™ on these modes requires the optional S3100 module.
Large SolarMAX™ HD Display
The 12-inch SolarMAX™ HD touchscreen offers sharp image quality with a 1280 x 800 resolution. The display remains highly visible from wide viewing angles, in direct sunlight, and while using polarised glasses. Compatibility with C-MAP Discover, Reveal, and Navionics+ / Platinum charts ensures accurate mapping and navigation performance.
Advanced Connectivity And Expansion
The HDS PRO 12 supports extensive integration with modern marine electronics and entertainment systems. Compatible accessories include Halo radar, NAC1 and NAC2 autopilot systems, NMEA 2000®, USB connectivity, and SiriusXM® Weather/Audio services.
ActiveTarget® 2 Live Sonar support provides real-time, high-resolution views of fish movement and underwater structures. The system also supports plug-and-play installation of two ActiveTarget® units simultaneously, enabling multiple sonar views and expanded Front and Scout modes for enhanced bait tracking.
Technical Data
Brand Lowrance Article Number 000-16003-001 Product Fishfinder HDS PRO 12 No Transducer Model HDS PRO 12 Display Size 12" Resolution 1280 x 800 Supplied Transducer No Transducer Ports Dual 9 Pin Xsonic Sonar Power 1 kW Per Channel Connections NMEA 2000 + USB Barcode 9420064129836 Product Code 5605339
