Lowrance 000-15988-001 - Fishfinder HDS PRO 12 Transducer Active Imaging 3-In-1

Lowrance 000-15988-001 - Fishfinder HDS PRO 12 Transducer Active Imaging 3-In-1

The Lowrance HDS PRO 12 fishfinder with Active Imaging™ 3-In-1 transducer delivers professional-level sonar performance, ultra-high-definition imaging, and advanced marine integration capabilities. Designed as part of the latest HDS PRO range, this system provides exceptional underwater visibility and accurate fish tracking with support for Active Imaging™ HD and optional ActiveTarget® live sonar technology.

Advanced Sonar And Imaging Technology

The built-in next-generation sonar system features dual independent 9 Pin Xsonic transducer ports with up to 1 kW output per channel. The included Active Imaging™ HD transducer provides detailed Lowrance CHIRP sonar, SideScan, and DownScan Imaging™ views for precise fish and structure detection.

FishReveal™ technology is supported on both SideScan and DownScan modes, helping identify fish around and beneath the vessel more effectively. FishReveal™ support on these imaging modes requires the optional S3100 module.

Large SolarMAX™ HD Touchscreen

The 12-inch SolarMAX™ HD touchscreen delivers sharp and vivid images with a 1280 x 800 resolution. The display remains highly visible from wide viewing angles, in bright sunlight, and while wearing polarised glasses. Full support for C-MAP Discover, Reveal, and Navionics+ / Platinum charts ensures reliable navigation and detailed mapping performance.

Comprehensive Marine Integration

The HDS PRO 12 supports seamless integration with a wide range of marine electronics and onboard systems. Compatible accessories include Halo radar, NAC1 and NAC2 autopilot systems, NMEA 2000®, USB connectivity, and SiriusXM® Weather/Audio services.

Support for ActiveTarget® 2 Live Sonar provides high-resolution real-time views of fish movement and underwater structures. The unit also supports simultaneous installation of two ActiveTarget® systems, enabling multiple sonar perspectives with expanded Front and Scout modes for advanced bait tracking.

Technical Data

Brand: Lowrance
