Lowrance 000-15706-001 - Fishfinder Elite FS 9 Without Transducer

ID 1341365

$ 1,657.23

1-2 weeks delivery time

- +

Add to cart

The Lowrance Elite FS 9 without transducer provides a large display and advanced fishfinding performance with support for ActiveTarget® 2 Live Sonar, Active Imaging™ HD, extensive chart compatibility, and precise GPS positioning.

Description
Ask a Question

Lowrance 000-15706-001 - Fishfinder Elite FS 9 Without Transducer

The Lowrance Elite FS 9 without transducer is built for anglers who need a larger display and advanced fishfinding performance. It supports the full Lowrance sonar ecosystem, including ActiveTarget® 2 Live Sonar and Active Imaging™ HD, along with extensive chart compatibility and precise GPS positioning.

Active Imaging HD requires S3100 Module.

Display

Resolution	800 x 480 px
Backlight Color	Pure White LED
Screen Brightness	>1200 nits
Viewing Angles	50° top / 60° bottom / 70° left-right

Sonar

Frequency

40-250 / 455-800 kHz

Connectivity

Bluetooth	Integrated Bluetooth 4.0 with Bluetooth Classic support
Wi-Fi	Internal 802.11b/g/n
Ethernet Ports	1 x 100 Mbit
NMEA 0183	Not supported
NMEA 2000	1 x Micro-C
PC Connectivity	None
SD Card Storage	1 micro SD card up to 32 GB
Video	None

Cartography

Charts Supported

C-MAP MAX N, MAX N+, C-MAP Genesis, C-MAP Precision Contour HD (Amer only), Navionics Gold, Navionics+, Platinum+, Insight Pro, Insight HD, Lowrance Regional Mapping Partners

Electrical

Supply Voltage	12 V DC (10.8–17 VDC)
Power Consumption	2.0 A @ 13 VDC
Recommended Fuse Rating	3 A

GPS

Correction	DGPS, WAAS, MSAS, EGNOS, GLONASS
Receiver Channels	16
Position Accuracy	20 m RMS
Time To First Fix	30 s
Update Rate	10 Hz

Environment

Operating Temperature	-15°C to 55°C
Storage Temperature	-20°C to 60°C
Humidity	95% RH at 60°C for 18 hours
Shock / Vibration	100,000 cycles of 20 G
Protection Rating	IPX7 (card door closed)

Brand: Lowrance
