Lowrance 000-16000-001 - HDS-10 Pro No Transducer
Advanced fishfinder and chartplotter designed for high-precision fishing and navigation. Supports ActiveTarget® 2 Live Sonar and ultra high-definition Active Imaging™ HD, delivering real-time fish and structure visibility with full system networking.
Display
Screen Size 10" Resolution 1280 x 800 px Backlight Color Pure White LED Screen Brightness >1200 nits Viewing Angles 80° top/bottom, 80° left/right Screen Type Touchscreen
Sonar And GPS
Frequency 40–250 / 455–1200 kHz GPS Correction DGPS, WAAS GPS Channels 16 Position Accuracy 20 m RMS Time To First Fix 30 s Update Rate 10 Hz
Connectivity
Ethernet Ports 1 x 100 Mbit Bluetooth Bluetooth 4.0 WiFi 802.11 b/g/n NMEA 0183 TX/RX GPS, Navigation, Sonar, Compass, Wind, AIS/DSC NMEA 2000 1 x Micro-C SD Card Storage 2 x micro SD up to 32GB PC Connectivity None
Cartography And Autopilot
Charts Supported C-MAP Reveal, Discover, Reveal X, Discover X, MAX N, MAX N+, Genesis, Precision Contour HD (Amer Only), Navionics Gold, Nav+, Platinum+, Insight Pro, Insight HD Autopilot Turn Patterns Course, Heading, Waypoint, Power Steer, U-Turn, C-Turn, Spiral, Zigzag, Square, Lazy-S Steering Modes Course, Heading, Waypoint, Power Steer
Electrical And Environment
Voltage 12 V DC (10.8–17 VDC) Consumption 26 W Power Consumption Max 2.9 A @ 13.8 VDC Power Consumption Min 2.0 A @ 13 VDC Recommended Fuse 3 A Protection Rating IPX6 & IPX7 Operating Temperature -15°C to 55°C Storage Temperature -20°C to 60°C Humidity 95% Relative Humidity, 48 hrs Shock Vibration 100,000 cycles of 20 G Weight 1.66 kg Depth 121.39 mm
Brand: Lowrance
Barcode: 9420064129805 -
