The BEP 185070P-01-1 is a heavy-duty single pole thermal circuit breaker rated at 70A (30V DC) with a switchable reset mechanism and panel mount (flush mount) installation. It provides 3000A interrupt capacity, IP67 protection, and visible trip indication, making it suitable for auxiliary circuits in marine and vehicle applications, including engine compartments and bilge areas.
- Description
- Ask a Question
-
BEP 185070P-01-1 – HD Thermal Circuit Breaker 70A, Switchable Reset, Panel Mount (Flush), 30V DC, IP67
The BEP 185070P-01-1 is a heavy-duty single pole thermal type circuit breaker designed for reliable protection of auxiliary and accessory circuits in demanding 30V DC electrical systems. With a rated current of 70A, it is suitable for use across trucks, buses, RVs, and marine installations.
This model features a switchable reset mechanism and can be manually switched to isolate the circuit. A unique reset mechanism provides visible indication of a tripped condition, supporting safer operation and simpler troubleshooting.
Key Features
- Product Number: 185070P-01-1
- Type: Heavy-duty single pole thermal type breaker
- Rated Current: 70A
- Rated Voltage: 30V DC
- Interrupt Capacity: 3000A
- Reset Type: Switchable Reset (manual switching available)
- Mounting: Panel mount (flush mount)
- Terminal Stud Torque: 50 in-lb (5.6Nm) max.
- Ingress Protection Rating: IP67
Applications
- Auxiliary and accessory circuits
- Trucks, buses, RVs, and marine applications
- Battery chargers
- DC audio systems
- Engine compartment and bilge area installations (sealed series)
Temperature Ranges
- Operating Temperature: -25°F (-32°C) to 180°F (82°C)
- Storage Temperature: -30°F (-34°C) to 300°F (149°C)
Construction
- Housing: Thermoset plastic
- UL Rating: 94V0
- Material Temperature Rating: 311°F (155°C)
- Hardware: Tin plated copper studs, brass rivets, stainless steel locking nuts
- Stud Insulators: Provided on covered units with F (Surface Mount) bases
Approvals
- Complies with SAEJ1625
- Complies with J1171
- Complies with UL1500 (Ignition protected)
Product Summary
Specification Value Model BEP 185070P-01-1 Rated Current 70A Rated Voltage 30V DC Mounting Type Panel Mount (Flush Mount) Reset Type Switchable Reset Interrupt Capacity 3000A Ingress Protection IP67 -
