ID
1317250
$ 223.53
1-2 weeks delivery time
-
+
This Wika Bourdon tube pressure gauge features a stainless steel measuring system designed for accurate measurement of gases and liquids across various sectors including pneumatics, hydraulics, shipping, chemical, and food industries, with an accuracy class 1.0 per DIN 16005. It has a 100 mm stainless steel 304 case with a bottom connection and back flange, a white dial with black lettering, black pointer, safety glass or polycarbonate window, and is glycerine-filled. The measuring range is 0 to 10 bar and the product code is 40.26.603.
- Description
- Ask a Question
-
Wika Bourdon Tube Pressure Gauge Stainless Steel, Case Ø 100mm Bottom Connection With Back Flange 1/2'' 0-10 Bar
This model of Bourdon tube pressure gauges uses a stainless steel measuring system designed for measuring gases and liquids in sectors such as pneumatics, hydraulics, shipping, chemical, and food industries. It offers an accuracy class 1.0 according to DIN 16005 standards.
- Case diameter: Ø 100 mm with bottom connection and back flange
- Case made from stainless steel 304
- 316Ti stainless steel measuring system
- Dial: white with black lettering
- Pointer color: black
- Window material: safety glass/polycarbonate
- Glycerine-filled case
- Dimensions as specified in DIN16064
- Product code: 40.26.603
- Connection type: 1/2" BSP bottom connection with back flange
- Measuring range: 0 - 10 bar
-
