ID
1317254
$ 223.53
1-2 weeks delivery time
-
+
Engineered for versatility, this Wika Bourdon tube pressure gauge features a stainless steel measuring system within a 100 mm stainless steel 304 case, bottom connection, and back flange, suitable for accurate measurement of gases and liquids in multiple industries. The dial is white with black lettering, pointer is black, and the window is safety glass or polycarbonate; the case is glycerine-filled. It meets accuracy class 1.0 per DIN 16005 and has a measuring range of -1 to +1.5 bar, product code 40.26.703.
- Description
- Ask a Question
-
Wika Bourdon Tube Pressure Gauge Stainless Steel, Case Ø 100mm Bottom Connection With Back Flange 1/2'' -1+1.5 Bar
Engineered for versatility, this Bourdon tube pressure gauge with a stainless steel measuring system is suitable for precise measurement of a wide range of gases and liquids across industries such as pneumatics, hydraulics, shipping, chemical, and food. Delivers accuracy class 1.0 as specified by DIN 16005.
- Case: Ø 100 mm, designed with bottom connection and back flange
- Case material: Stainless steel 304
- Measuring system: 316Ti stainless steel
- Dial: white, black lettering
- Pointer: black
- Window: safety glass or polycarbonate
- Case fill: glycerine
- Dimensions: as per DIN16064
- Product code: 40.26.703
- Connection: 1/2" BSP bottom connection with back flange
- Measuring range: -1 + 1.5 bar
-
