ID
1317256
$ 223.53
1-2 weeks delivery time
-
+
Designed for demanding environments, this Wika Bourdon tube pressure gauge includes a stainless steel measuring system within a 100 mm stainless steel 304 case with bottom connection and back flange. It has a white dial with black lettering, black pointer, safety glass or polycarbonate window, and a glycerine-filled case. Meeting accuracy class 1.0 per DIN 16005, it measures pressures from -1 to +5 bar and is identified by product code 40.26.705.
- Description
- Ask a Question
-
Wika Bourdon Tube Pressure Gauge Stainless Steel, Case Ø 100mm Bottom Connection With Back Flange 1/2'' -1+5 Bar
Designed for demanding environments, this Bourdon tube pressure gauge incorporates a stainless steel measuring system, appropriate for measuring all types of gases and liquids in pneumatics, hydraulics, shipping, chemical, and food applications. It offers a high degree of accuracy in line with DIN 16005 class 1.0.
- Case: Ø 100 mm, equipped with bottom connection and back flange
- Case material: Stainless steel 304
- Measuring system: 316Ti stainless steel
- Dial: white with black lettering
- Pointer: black
- Window: safety glass or polycarbonate
- Case fill: glycerine
- Dimensions: as per DIN16064
- Product code: 40.26.705
- Connection: 1/2" BSP bottom connection with back flange
- Measuring range: -1 + 5 bar
-
