ID
1317252
$ 223.53
1-2 weeks delivery time
-
+
This Bourdon tube pressure gauge by Wika combines a stainless steel measuring system with a robust 100 mm stainless steel 304 case, bottom connection, and back flange, designed for measuring gases and liquids in various industries like pneumatics, hydraulics, and shipping. It features a white dial with black lettering, black pointer, safety glass or polycarbonate window, glycerine-filled case, and meets accuracy class 1.0 under DIN 16005. The measuring range is -1 to 0 bar, with product code 40.26.701.
- Description
- Ask a Question
-
Wika Bourdon Tube Pressure Gauge Stainless Steel, Case Ø 100mm Bottom Connection With Back Flange 1/2'' -1+0 Bar
This Bourdon tube pressure gauge combines a stainless steel measuring system with robust design to measure gases and liquids in various industries including pneumatics, hydraulics, and shipping. It meets accuracy class 1.0 as per DIN 16005 guidelines.
- Case diameter: Ø 100 mm, with bottom connection and back flange
- Constructed with stainless steel 304 case
- 316Ti stainless steel measuring system
- Dial: white background and black lettering
- Black pointer
- Window composed of safety glass/polycarbonate
- Case filled with glycerine
- Dimensions according to DIN16064
- Product code: 40.26.701
- Connection: 1/2" BSP bottom connection with back flange
- Measuring range: -1 + 0 bar
-
