ID
1317248
$ 223.53
1-2 weeks delivery time
-
+
This Wika Bourdon Tube Pressure Gauge with a Ø 100 mm stainless steel case and 1/2'' bottom connection includes a back flange for installation flexibility. It features a 316Ti measuring system, glycerine case fill, and meets accuracy class 1.0 (DIN 16005), measuring pressures from 0 to 4 bar.
- Description
- Ask a Question
-
Wika Bourdon Tube Pressure Gauge Stainless Steel, Case Ø 100mm Bottom Connection With Back Flange 1/2'' 0-4 Bar
Ideal for installation flexibility in the pneumatics, hydraulics, shipping, chemical, and food industries, this gauge includes a back flange and a 316Ti stainless steel measuring system. The large Ø 100 mm case and accuracy class 1.0 (DIN 16005) provide reliable measurement for a variety of gases and liquids.
- Case: Ø 100 mm, with bottom connection and back flange
- Case material: Stainless steel 304
- Measuring system: 316Ti stainless steel
- Dial: White with black lettering
- Pointer: Black
- Window: Safety glass/polycarbonate
- Case fill: Glycerine
- Dimensions: As per DIN16064
- Product code: 40.26.601
- Connection: 1/2" BSP bottom connection with back flange
- Measuring range: 0 - 4 bar
-
