Osculati AISI 316 Stainless Steel Countersunk Self-Tapping Screws DIN 7982 / UNI 6955, Ø2.9–6.3 mm

ID 1402629

$ 22.10

1-2 weeks delivery time

Diameter, mm:

Length, mm:

Item:

10 pcs
25 pcs
50 pcs
100 pcs
200 pcs

Osculati DIN 7982 / UNI 6955 self-tapping screws are manufactured from AISI 316 stainless steel and feature a flat countersunk head with a cross-recessed drive. Their tapered head design allows flush installation in suitably prepared countersunk holes, making them suitable for mounting compatible marine fittings, panels and mechanical components. The self-tapping thread forms a mating thread in appropriate materials, while AISI 316 stainless steel provides corrosion resistance for marine and outdoor environments. The range includes 45 dimensional configurations with diameters from 2.9 to 6.3 mm and lengths from 10 to 60 mm. Each variant is supplied in a box containing 10, 25, 50, 100 or 200 screws, depending on the selected size.

Description
Ask a Question

Osculati AISI 316 Stainless Steel Countersunk Self-Tapping Screws DIN 7982 / UNI 6955

Osculati countersunk self-tapping screws are manufactured from AISI 316 stainless steel and feature a cross-recessed drive. Listed according to DIN 7982 and UNI 6955, these screws are designed for fastening compatible panels, fittings and mechanical components where a flush mounting surface is required.

The flat countersunk head has a tapered underside that fits into a suitably prepared countersunk hole. Once installed correctly, the screw head can sit flush with the surrounding surface. This distinguishes DIN 7982 screws from DIN 7981 pan head screws, whose heads remain above the mounting surface.

The self-tapping thread is designed to form a mating thread in compatible materials during installation. Depending on the substrate, material thickness and fastening requirements, a correctly sized pilot hole may be necessary. The cross-recessed drive allows installation using a matching screwdriver or driver bit.

AISI 316 stainless steel provides corrosion resistance for suitable marine, outdoor and general maintenance applications. The selected screw size and installation conditions should be appropriate for the materials being fastened.

The range includes 45 dimensional configurations across seven nominal diameters: 2.9, 3.5, 3.9, 4.2, 4.8, 5.5 and 6.3 mm. Available lengths range from 10 to 60 mm, depending on diameter. Each version is identified by an individual Osculati part number and supplied in a specified box quantity.

Technical Specifications

Brand	Osculati
Product Type	Self-Tapping Screw
Standards	DIN 7982 / UNI 6955
Material	AISI 316 Stainless Steel
Head Type	Flat Countersunk Head
Drive Type	Cross-Recessed
Thread Type	Self-Tapping
Available Diameters	2.9, 3.5, 3.9, 4.2, 4.8, 5.5, 6.3 mm
Available Length Range	10–60 mm
Box Quantities	10, 25, 50, 100, 200 pcs
Number of Variants	45
Dimensions Format	Diameter × Length

Features and Applications

AISI 316 stainless steel construction for corrosion resistance.
DIN 7982 / UNI 6955 self-tapping screw design.
Flat countersunk head for flush mounting in a suitable recess.
Cross-recessed drive for use with a compatible screwdriver bit.
Self-tapping thread for fastening in appropriate materials.
Suitable for compatible marine fittings, panels and mechanical assemblies.
Available in seven nominal diameters and 45 dimensional configurations.
Supplied in boxes containing 10 to 200 screws depending on size.

Available Sizes and Part Numbers

Diameter	Length	Box Quantity	Osculati Part No.
2.9 mm	10 mm	200 pcs	A4-7982-02.9X010
2.9 mm	13 mm	200 pcs	A4-7982-02.9X013
2.9 mm	19 mm	200 pcs	A4-7982-02.9X019
3.5 mm	10 mm	200 pcs	A4-7982-03.5X010
3.5 mm	13 mm	200 pcs	A4-7982-03.5X013
3.5 mm	16 mm	200 pcs	A4-7982-03.5X016
3.5 mm	19 mm	100 pcs	A4-7982-03.5X019
3.5 mm	25 mm	100 pcs	A4-7982-03.5X025
3.5 mm	32 mm	100 pcs	A4-7982-03.5X032
3.5 mm	38 mm	50 pcs	A4-7982-03.5X038
3.9 mm	10 mm	200 pcs	A4-7982-03.9X010
3.9 mm	16 mm	100 pcs	A4-7982-03.9X016
3.9 mm	19 mm	100 pcs	A4-7982-03.9X019
3.9 mm	22 mm	100 pcs	A4-7982-03.9X022
3.9 mm	25 mm	100 pcs	A4-7982-03.9X025
3.9 mm	32 mm	50 pcs	A4-7982-03.9X032
3.9 mm	38 mm	50 pcs	A4-7982-03.9X038
4.2 mm	10 mm	100 pcs	A4-7982-04.2X010
4.2 mm	16 mm	100 pcs	A4-7982-04.2X016
4.2 mm	19 mm	100 pcs	A4-7982-04.2X019
4.2 mm	22 mm	100 pcs	A4-7982-04.2X022
4.2 mm	25 mm	100 pcs	A4-7982-04.2X025
4.2 mm	32 mm	50 pcs	A4-7982-04.2X032
4.2 mm	38 mm	50 pcs	A4-7982-04.2X038
4.2 mm	45 mm	50 pcs	A4-7982-04.2X045
4.2 mm	50 mm	25 pcs	A4-7982-04.2X050
4.8 mm	13 mm	100 pcs	A4-7982-04.8X013
4.8 mm	16 mm	100 pcs	A4-7982-04.8X016
4.8 mm	19 mm	50 pcs	A4-7982-04.8X019
4.8 mm	22 mm	50 pcs	A4-7982-04.8X022
4.8 mm	25 mm	50 pcs	A4-7982-04.8X025
4.8 mm	32 mm	50 pcs	A4-7982-04.8X032
4.8 mm	38 mm	50 pcs	A4-7982-04.8X038
4.8 mm	45 mm	25 pcs	A4-7982-04.8X045
4.8 mm	50 mm	25 pcs	A4-7982-04.8X050
5.5 mm	16 mm	50 pcs	A4-7982-05.5X016
5.5 mm	22 mm	50 pcs	A4-7982-05.5X022
5.5 mm	32 mm	25 pcs	A4-7982-05.5X032
5.5 mm	38 mm	25 pcs	A4-7982-05.5X038
5.5 mm	50 mm	25 pcs	A4-7982-05.5X050
6.3 mm	19 mm	50 pcs	A4-7982-06.3X019
6.3 mm	25 mm	25 pcs	A4-7982-06.3X025
6.3 mm	32 mm	25 pcs	A4-7982-06.3X032
6.3 mm	45 mm	25 pcs	A4-7982-06.3X045
6.3 mm	60 mm	10 pcs	A4-7982-06.3X060

Size Selection

Select the required nominal screw diameter and length according to the materials and components being fastened. The mounting surface must accommodate the countersunk head, and the screw must provide suitable thread engagement.

Available lengths vary by diameter. Each dimensional configuration has a fixed box quantity, as specified in the table above. A suitable pilot hole may be required depending on the substrate and installation conditions.
