Osculati A2 AISI 304 Stainless Steel Flat Washers DIN 125 / UNI 6592, M3–M16

ID 1403704

$ 4.42

1-2 weeks delivery time

Diameter, mm:

Item:

25 pcs
50 pcs
100 pcs
200 pcs

Osculati DIN 125 / UNI 6592 flat washers are manufactured from A2 (AISI 304) stainless steel and feature a flat, circular design with a central hole for compatible metric bolts, screws and threaded rods. Installed beneath a bolt head or nut, they help distribute the clamping load over a larger contact area and protect the mounting surface from direct contact with the fastener. Their stainless steel construction offers corrosion resistance for general mechanical, outdoor and suitable marine applications. Available in nine nominal sizes from M3 to M16, these washers are supplied in cardboard boxes containing 25, 50, 100 or 200 pieces, depending on the selected size.

Description
Ask a Question

Osculati A2 AISI 304 Stainless Steel Flat Washers DIN 125 / UNI 6592

Osculati flat washers are manufactured from A2 (AISI 304) stainless steel and are listed according to DIN 125 / UNI 6592. These standard round washers feature a flat bearing surface and a central hole designed to accommodate compatible metric threaded fasteners.

Installed beneath a bolt head, machine screw head or nut, a flat washer helps distribute the clamping force over a larger area of the mounting surface. This can reduce localized contact pressure and help protect the surface of the assembled components.

The flat circular profile makes these washers suitable for a wide range of mechanical fastening applications. They can be used with compatible bolts, screws, nuts and threaded rods, provided that the washer size and mounting requirements are correctly matched.

Unlike split spring washers or serrated lock washers, standard DIN 125 flat washers do not incorporate a dedicated anti-loosening mechanism. They are intended primarily for load distribution and surface protection rather than vibration locking or sealing.

A2 (AISI 304) stainless steel provides corrosion resistance for general indoor, outdoor and suitable marine applications. For installations exposed to prolonged saltwater contact or high chloride concentrations, the suitability of this stainless steel grade should be assessed.

The range includes nine nominal sizes corresponding to metric fasteners from M3 to M16. Each size has an individual Osculati part number and is supplied in a cardboard box containing 25, 50, 100 or 200 washers.

Technical Specifications

Brand	Osculati
Product Type	Standard Flat Washer
Standards	DIN 125 / UNI 6592
Material	A2 / AISI 304 Stainless Steel
Shape	Flat Circular Washer
Design	Plain, Non-Serrated
Compatible Nominal Fastener Sizes	M3, M4, M5, M6, M8, M10, M12, M14, M16
Box Quantities	25, 50, 100, 200 pcs
Packaging	Cardboard Box
Number of Variants	9

Features and Applications

Manufactured from A2 (AISI 304) stainless steel.
Standard flat washer design according to DIN 125 / UNI 6592.
Flat circular body with a central mounting hole.
Helps distribute fastening loads beneath bolt heads and nuts.
Helps reduce localized pressure against the mounting surface.
Suitable for use with appropriately sized metric bolts, machine screws and threaded rods.
Applicable to equipment mounting, mechanical assemblies, brackets, panels and general fastening installations.
Available in nine nominal sizes from M3 to M16.
Supplied in cardboard boxes containing 25 to 200 washers.

Available Sizes and Part Numbers

Nominal Size	Box Quantity	Osculati Part No.
M3	200 pcs	A2-125-03
M4	200 pcs	A2-125-04
M5	200 pcs	A2-125-05
M6	200 pcs	A2-125-06
M8	200 pcs	A2-125-08
M10	100 pcs	A2-125-10
M12	50 pcs	A2-125-12
M14	25 pcs	A2-125-14
M16	25 pcs	A2-125-16

Size Selection

Select the nominal washer size according to the metric bolt, screw or threaded rod used in the assembly. The nominal designation refers to the compatible fastener size and should not be interpreted as the washer's exact inner or outer diameter.

Each nominal size has a fixed box quantity, as shown above. Exact inner diameters, outer diameters, thicknesses and dimensional tolerances are not provided in the supplied catalogue information.
