MME Rectangular Zinc Weld-On Hull & Rudder Anodes with Mounting Strips

MME Rectangular Zinc Weld-On Sacrificial Anodes with Mounting Strips – 200–920 mm

The MME Rectangular Zinc Weld-On Anodes are designed to provide sacrificial corrosion protection for marine metal structures. Manufactured from zinc, these anodes feature rectangular bodies with extended mounting strips for welded installation.

The range includes nine models with different body dimensions and mounting strip lengths. Anode body lengths range from 200 to 920 mm, widths from 85 to 155 mm and heights from 30 to 51 mm. The mounting strips range from 310 to 1075 mm in length, depending on the selected model.

Key Features

• Brand: MME
• Product Type: Sacrificial weld-on anode
• Anode Material: Zinc
• Shape: Rectangular
• Installation Type: Weld-on
• Mounting Arrangement: Extended mounting strip
• Application: Corrosion protection of marine metal structures
• Function: Sacrificial corrosion protection
• Body Length Range: 200–920 mm
• Body Width Range: 85–155 mm
• Body Height Range: 30–51 mm
• Mounting Strip Length Range: 310–1075 mm
• Available Variants: 9 models
• Sales Unit: 1 piece

Technical Specifications and Available Models

The MME zinc anode range includes nine rectangular models with different body dimensions and mounting strip lengths. All dimensions are specified in millimetres.

Construction and Mounting

Each MME anode consists of a rectangular zinc body with an extended mounting strip. The strip provides the mounting arrangement for welded installation on the required marine structure.

The following mounting strip lengths are specified for the individual models:

• MME4Z: 440 mm.
• MME4ZS: 310 mm.
• MME5ZS: 440 mm.
• MME8Z: 405 mm.
• MME10ZS: 500 mm.
• MME11Z: 500 mm.
• MME20Z: 680 mm.
• MME25Z: 940 mm.
• MME35Z: 1075 mm.

The mounting strip length is a separate specification from the anode body length. Both dimensions should be considered when selecting an anode for an existing installation.

Dimensions and Model Selection

The range includes nine models with different zinc body dimensions. Body dimensions are specified as length × width × height.

Compact Anodes – 200–350 mm

• MME4Z: Zinc body measuring 305 × 85 × 45 mm, with a 440 mm mounting strip.
• MME4ZS: Zinc body measuring 200 × 105 × 35 mm, with a 310 mm mounting strip.
• MME5ZS: Zinc body measuring 270 × 100 × 40 mm, with a 440 mm mounting strip.
• MME8Z: Zinc body measuring 300 × 155 × 30 mm, with a 405 mm mounting strip.
• MME10ZS: Zinc body measuring 350 × 155 × 38 mm, with a 500 mm mounting strip.

Medium and Long Anodes – 400–920 mm

• MME11Z: Zinc body measuring 400 × 150 × 33 mm, with a 500 mm mounting strip.
• MME20Z: Zinc body measuring 535 × 135 × 51 mm, with a 680 mm mounting strip.
• MME25Z: Zinc body measuring 800 × 120 × 40 mm, with a 940 mm mounting strip.
• MME35Z: Zinc body measuring 920 × 130 × 50 mm, with a 1075 mm mounting strip.

The MME4Z and MME5ZS have the same mounting strip length of 440 mm but different body dimensions.

The MME10ZS and MME11Z share a mounting strip length of 500 mm. Their body dimensions differ, with the MME10ZS measuring 350 × 155 × 38 mm and the MME11Z measuring 400 × 150 × 33 mm.

The MME35Z is the longest model in the range, featuring a 920 mm anode body and a 1075 mm mounting strip.

When selecting a replacement anode, compare the body dimensions and mounting strip length with the existing installation and available mounting space.

Corrosion Protection and Application

The MME zinc anodes are designed to provide sacrificial corrosion protection for marine metal components and structures. The zinc body functions as a sacrificial component, corroding preferentially to help protect the connected metal structure against corrosion.

The range is available in nine sizes with different body dimensions and mounting strip lengths. The extended mounting strips are intended for welded installation.

Product Identification

The following table lists the manufacturer product numbers and corresponding EAN codes for all nine variants.

Sales Unit: 1 zinc weld-on sacrificial anode.
