ID
1398628
$ 21.19
1-2 weeks delivery time
Size:
- 150x60x25
- 250x65x28
- 350x70x38
The Hollex Type V Aluminium Anode is a rectangular sacrificial anode designed for corrosion protection of boat hulls and rudders in brackish water environments. Available in three models: V 15C (150 × 60 × 25 mm), V 25C (250 × 65 × 28 mm) and V 35C (350 × 70 × 38 mm). The anodes feature mounting hole spacings of 80, 140 or 200 mm, depending on the model, with a uniform hole diameter of 11 mm. Manufactured from aluminium, these anodes provide sacrificial protection for metal components and are supplied individually.
- Description
- Ask a Question
-
Hollex Type V Aluminium Hull and Rudder Anode – Rectangular, 150–350 mm
The Hollex Type V Aluminium Hull and Rudder Anode is a rectangular sacrificial anode designed to protect metal components of boats against corrosion. Manufactured from aluminium, it is suitable for use in brackish water environments where freshwater and saltwater mix.
The anode is designed for installation on boat hulls and rudders and features two mounting holes. Three models are available, with body lengths of 150, 250 and 350 mm. Each version has an 11 mm mounting hole diameter, while the hole spacing and overall body dimensions vary by model.
Key Features
- Brand: Hollex
- Product Type: Sacrificial hull and rudder anode
- Series: Type V
- Material: Aluminium
- Shape: Rectangular
- Application: Boat hulls and rudders
- Suitable Water Type: Brackish water
- Function: Sacrificial corrosion protection for metal components
- Mounting: Two mounting holes
- Hole Diameter: 11 mm
- Available Models: V 15C, V 25C and V 35C
- Sales Unit: 1 piece
Technical Specifications and Available Models
Specification V 15C V 25C V 35C Product Number 5953 5955 5957 Material Aluminium Aluminium Aluminium Shape Rectangular Rectangular Rectangular Length 150 mm 250 mm 350 mm Width 60 mm 65 mm 70 mm Height 25 mm 28 mm 38 mm Hole Spacing (H.o.H.) 80 mm 140 mm 200 mm Hole Diameter 11 mm 11 mm 11 mm Sales Unit 1 piece 1 piece 1 piece
Dimensions and Model Selection
The Type V series includes three aluminium anodes with different body dimensions and mounting hole spacings. Body dimensions are specified as length × width × height.
- V 15C (5953): 150 × 60 × 25 mm body, 80 mm hole spacing and 11 mm hole diameter.
- V 25C (5955): 250 × 65 × 28 mm body, 140 mm hole spacing and 11 mm hole diameter.
- V 35C (5957): 350 × 70 × 38 mm body, 200 mm hole spacing and 11 mm hole diameter.
Mounting and Corrosion Protection
The rectangular anode features two mounting holes for installation on the boat's hull or rudder. When selecting a replacement anode, the overall body dimensions, hole spacing and hole diameter should be matched to the required installation dimensions.
The aluminium anode acts as a sacrificial component, corroding preferentially to help protect other metal parts of the vessel from corrosion damage.
The appropriate anode material depends on the water environment in which the vessel operates:
- Magnesium Anodes: Suitable for freshwater environments.
- Zinc Anodes: Suitable for saltwater environments.
- Aluminium Anodes: Suitable for brackish water environments where freshwater and saltwater mix.
Product Identification
Model Product Number EAN Code V 15C 5953 1957000002529 V 25C 5955 1957000002536 V 35C 5957 1957000002543
Package Contents: 1 aluminium hull and rudder anode.
-
