ID
1282124
$ 5,888.42
1-2 weeks delivery time
-
+
The Maxwell VWC 1000 hydraulic anchor windlass (article Vetus P102762) is a vertical hydraulic windlass designed for automatic handling of chain-only anchor rodes. Featuring a 50TDC clockwise (CW) chainwheel and an independent capstan, it supports 6–10 mm chain, delivers a maximum pull of 700 kg, weighs 24 kg, and provides controlled free-fall anchoring together with docking and secondary rope handling capability.
- Description
- Ask a Question
-
Maxwell VWC 1000 Vertical Hydraulic Anchor Windlass with Capstan 50TDC CW (Vetus P102762)
The Maxwell VWC Series 1000 hydraulic anchor windlass is engineered for automatic vertical handling of chain-only anchor rodes while offering enhanced versatility through an independent capstan. This configuration allows retrieval of a secondary rope or rope and chain rode and can assist with docking procedures. The 50TDC chainwheel provides a maximum deck clearance of 50 mm, and the clockwise (CW) configuration supports specific installation and operational requirements.
Design and Functional Features
- Designed for automatic vertical handling of chain-only anchor rodes
- Independent capstan for retrieval of secondary rope or rope and chain rode
- Clockwise (CW) anchor retrieval configuration
- Fully automatic single or dual direction chainwheel operation
- Clutch disengagement of the chainwheel enabling independent rope hauling from any direction
- MAX-grip™ snag-free warping drum providing positive control of all ropes
- Integral chain pipe and stripper aligned for virtually jam-free chain handling
Construction and Materials
- Above-deck components manufactured from marine-grade stainless steel (AISI 316)
- Anodized aluminium gearbox and spacer tube on all models
- Robust construction suitable for integration with hydraulic drive systems
- Marine-grade stainless steel bolts ensuring precise alignment of gearbox and topworks
Brake and Control System
- Cone-type brake and clutch mechanism permitting manual free-fall anchoring
- Smooth progressive clutch engagement ensuring safe and precise operator control
- Chainwheel locking pawl for secure anchoring operation
Installation and Maintenance
- Simple through-deck installation enabled by modular design
- Precise alignment of gearbox to topworks for reliable long-term operation
- Easily disassembled construction for servicing and routine maintenance
- Low-profile configurations without warping drum available within the VWC series
Technical Specifications
Parameter Specification Drive Type Hydraulic Configuration Vertical Rode Type Chain Capstan / Drum Yes Chainwheel Type 50TDC CW Maximum Pull / Lift 700 kg Supported Chain Size 6 – 10 mm Short Link Chain Size 6 – 10 mm Weight 24 kg -
