ID
1300723
$ 4,456.56
1-2 weeks delivery time
-
+
The Maxwell VWLP 1500 hydraulic anchor windlass (article Vetus P100452) is a vertical hydraulic windlass designed for sailing boats with limited anchor locker space. Intended for traditional rope and chain anchor rodes with manual transfer to the chainwheel, it supports 6–10 mm chain, delivers a maximum pull of 850 kg, weighs 22 kg, and features a compact drum-less configuration optimized for efficient below-deck installation.
- Description
- Ask a Question
-
Maxwell VWLP 1500 Vertical Hydraulic Anchor Windlass (Vetus P100452)
The Maxwell VW Series VWLP 1500 hydraulic anchor windlass is engineered for sailing vessels where anchor locker space is limited and a compact anchoring solution is required. It is designed for traditional rope and chain combination anchor rodes, where manual transfer of the rode from the rope warping drum to the chainwheel is necessary. The vertical configuration and modular construction allow efficient installation inside confined anchor lockers, including alternative horizontal mounting on a fore-and-aft bulkhead for below-deck applications.
Design and Functional Features
- Designed for traditional rope and chain anchor rodes with manual transfer to the chainwheel
- Independent MAX-grip™ snag-free rope warping drum enabling rope hauling from any direction
- Chainwheel clutch disengagement for positive and controlled rope handling
- Capability to operate two anchors from a single windlass unit
- Permits use of traditional shackle and thimble rope-to-chain connections
- Vertical configuration optimized for compact anchor locker installations
Construction and Materials
- Above-deck components manufactured from marine-grade stainless steel (AISI 316) and chromed bronze
- Anodized aluminium gearbox and spacer for enhanced corrosion resistance and durability
- Marine-grade stainless steel (AISI 316) fasteners ensuring precise alignment of gearbox and topworks
- Robust construction suitable for integration with hydraulic drive systems
Brake and Control System
- Cone-type brake and clutch mechanism permitting manual free-fall anchoring
- Smooth progressive clutch engagement ensuring safe operator control
- Chainwheel locking pawl for secure anchoring operation
Installation and Maintenance
- Modular design simplifies through-deck installation
- Allows horizontal mounting on fore-and-aft bulkheads inside the chain locker
- Easily disassembled construction for servicing and routine maintenance
Technical Specifications
Parameter Specification Drive Type Hydraulic Configuration Vertical Rode Type Chain Warping Drum No Maximum Pull / Lift 850 kg Supported Chain Size 6 – 10 mm Weight 22 kg -
