ID
1344872
$ 199.76
1-2 weeks delivery time
-
+
The Exalto EWT wiper 215 BD 12 V with 75 mm shaft is a self-parking single-drive motor with IP66 protection, designed for reliable operation in open and exposed marine installations.
- Description
- Ask a Question
-
Exalto EWT Wiper 215 BD 12V 75mm Shaft Black Insulated Earth
The Exalto EWT 215 BD with a 75 mm shaft is a self-parking single-drive wiper motor for glass and bulkhead mounting. It supports speed interval operation and can be adapted for parallel configurations. Its IP66-rated waterproof housing makes it suitable for exposed marine environments.
Key Features
- Self-parking wiper motor
- Single-drive design
- Speed interval: yes
- Glass and bulkhead mounting
- Fully waterproof IP66 housing
- Parallel use possible
Technical Data
Sales Unit 1 Pieces Voltage (V) 12 VDC Power (W) 15 Torque (Nm) 15 Maximum Amperage (A) 3 Recommended Fuse Rating (A) 5 Drive Shaft Diameter (mm) 15 Shaft Length (mm) 75 Distance HoH (mm) 45 Arm Type LD Driven Axles 1 Blade Length (mm) 600 Maximum Arm Length (mm) 600 Maximum Blade Length (mm) 600 Protection Class (IP) IP66 Product Width (mm) 177.5 Product Depth (mm) 144 Product Height (mm) 100 Color Black Series LD Type VDC Wall Thickness (mm) 40–65 Suitable For LD-215BD
Brand: Exalto Wiper Technologies B.V. (Article code: 2151275IER.B / Barcode: 8720193089836)
-
