ID
1344873
$ 196.03
1-2 weeks delivery time
-
+
The Exalto EWT wiper 215 BD 24 V with 25 mm shaft is a self-parking single-drive motor for glass and bulkhead mounting, featuring IP66 waterproof protection, speed interval function, insulated earth, and suitability for parallel configurations.
- Description
- Ask a Question
-
Exalto EWT Wiper 215 BD 24V 25mm Shaft Black Insulated Earth
The Exalto EWT 215 BD 24V is a self-parking single-drive wiper motor suitable for glass and bulkhead mounting. It can be easily adapted for parallel use by means of a connection kit used with the parallel arm. The fully waterproof housing is rated up to IP66, making this wiper motor ideal for installation on a flying bridge or in an open cockpit.
Key Features
- Self-parking wiper motor
- Single-drive design
- Speed interval: yes
- Suitable for glass and bulkhead mounting
- Fully waterproof housing (IP66)
- Adaptable for parallel use
- Insulated earth (ungrounded)
Technical Data
Sales Unit 1 Pieces Voltage (V) 24 VDC Power (W) 15 Torque (Nm) 15 Maximum Amperage (A) 1.5 Recommended Fuse Rating (A) 4 Drive Shaft Diameter (mm) 15 Shaft Length (mm) 25 Distance HoH (mm) 45 Arm Type LD Driven Axles 1 Blade Length (mm) 600 Maximum Arm Length (mm) 600 Maximum Blade Length (mm) 600 Protection Class (IP) IP66 Product Width (mm) 177.5 Product Depth (mm) 94 Product Height (mm) 100 Color Black Series LD Type (VAC / VDC) VDC Wall Thickness (mm) 0–15 Suitable For LD-215BD
Brand: Exalto Wiper Technologies B.V. (Article code: 2152425IER.B / Barcode: 8720193079394)
-
