ID
1340234
$ 81.01
1-2 weeks delivery time
-
+
The ETA Thermal Circuit Breaker Type 4130 – 80 A is a rugged protection solution with a threaded flange design, offering high breaking capacity and reliable performance in industrial, automotive, and marine environments. It supports 240 V AC operation, features single-pole construction, compact dimensions, heavy-duty M6 screw connections, and a durable build suitable for demanding conditions. Brand: ETA.
- Description
- Ask a Question
-
ETA Thermal Circuit Breaker Type 4130 – 80 A
The ETA Thermal Circuit Breaker Type 4130 is a robust and versatile protection device engineered for demanding electrical environments. With a compact threaded flange design and high breaking capacity, it ensures reliable protection for electrical equipment, motors, generators, and vehicles across industrial, automotive, and marine applications.
Key Features
- Available current ratings from 20 A to 70 A (8 options)
- Nominal voltage ratings of 240 V AC and 50 V DC
- Breaking power (Icn) up to 800 A
- Operating ambient temperature range from -30 °C to +60 °C
- Trigger-free design, unaffected by external mechanical influences
- Degree of protection IP40, upgradeable to IP67 with optional protective cap
Service Life
- 240 V AC: Up to 500 maneuvers at 2 × IN (inductive or weakly inductive loads)
- 50 V DC: Up to 500 maneuvers at 2 × IN (inductive loads)
Advantages
- Compact dimensions with convenient threaded flange mounting
- Excellent quality-to-price ratio
- Wide range of applications including electrical equipment, engines, generators, utility vehicles, boating, and professional or DIY tools
- Rugged construction suitable for harsh and demanding environments
Applications
Ideal for protecting electrical appliances, machinery, motors, and generators in industrial, automotive, marine, and electrical sectors.
Technical Data
Rated Current 80 A Rated Voltage 240 V AC Number Of Poles 1 Height 87 mm Width 18 mm Length 32 mm Weight 0.55 kg Connection Type Heavy-Duty M6 Screws Mounting Type Threaded Flange
Brand: ETA
-
