Osculati Stainless Steel Press-Fitting Terminal

ID 1381878

$ 3.32

1-2 weeks delivery time

Size:

1/4" UNF
5/16" UNF
3/8" UNF
1/2" UNF
5/8" UNF

Item:

3 mm Wire
4 mm Wire
5 mm Wire
6 mm Wire
7 mm Wire
8 mm Wire
10 mm Wire

The Osculati Stainless Steel Press-Fitting Terminal is a marine-grade AISI 316 stainless steel right-hand threaded terminal designed for use with the Osculati modular turnbuckle system. Available with UNF threads from 1/4" to 5/8", it fits 3-10 mm wire rope and is intended for press-fitting installation. Combined with the Osculati turnbuckle body and left-hand jointed fork, it forms a complete adjustable standing rigging assembly.

Description
Ask a Question

Osculati Stainless Steel Press-Fitting Terminal – Right-Hand UNF Thread for Modular Turnbuckles

The Osculati Stainless Steel Press-Fitting Terminal is a precision-engineered component manufactured from marine-grade AISI 316 stainless steel. Designed as the right-hand press-fitting terminal for the Osculati modular turnbuckle system, it provides a strong, corrosion-resistant connection for standing rigging on sailing yachts and other marine vessels.

The terminal is intended for professional press-fitting onto wire rope and features precision UNF threads for smooth adjustment when assembled with the matching Osculati turnbuckle body and left-hand threaded fork.

Key Features

Original Osculati modular rigging component
Manufactured from marine-grade AISI 316 stainless steel
Right-hand UNF thread
Designed for professional press-fitting installation
Excellent corrosion resistance in marine environments
Suitable for standing rigging and wire rope systems

Available Variants

Osculati Code	UNF Thread	Wire Ø
07.185.01	1/4"	3 mm
07.185.02	5/16"	4 mm
07.185.03	5/16"	5 mm
07.185.04	3/8"	5 mm
07.185.05	3/8"	6 mm
07.185.06	1/2"	7 mm
07.185.07	1/2"	8 mm
07.185.08	5/8"	8 mm
07.185.09	5/8"	10 mm

Compatibility

This terminal is designed for use within the Osculati modular turnbuckle system and is assembled together with:

Osculati Stainless Steel Turnbuckle Body (A)
Osculati Stainless Steel Left-Hand Jointed Fork Terminal (B)

Together these components form the A+B+C turnbuckle configuration, providing a fully adjustable standing rigging assembly with excellent strength, corrosion resistance, and long-term marine reliability.
